Siemens SITOP DC power supply 6EP1332-1SH71

Siemens 6EP1332-1SH71 — SITOP DC power supply. DIN-rail primary-switched regulated 24 VDC power supply for automation panels.

Manufacturer part number (MPN)

6EP1332-1SH71 EAN / GTIN: 4025515152446 Sales unit: pcs Type of the power supply network: 1-phase AC Supply voltage: 120 V/230 V Input voltage 1 at AC: 85 ... 132 V Input voltage 2 at AC: 176 ... 264 V Buffering time for rated value of the output current in the event of power failure minimum: 20 ms Line frequency: 47 ... 63 Hz Input current at rated input voltage 120 V: 1.2 A Input current at rated input voltage 230 V: 0.67 A Current limitation of inrush current at 25 °C maximum: 13 A Fuse protection type: T 3,15 A/250 V (not accessible) Fuse protection type in the feeder: Recommended miniature circuit breaker: 16 A characteristic B or 10 A characteristic C Voltage curve at output: Controlled, isolated DC voltage Output voltage at DC rated value: 24 V Relative overall tolerance of the voltage: 3 % Residual ripple maximum: 150 mV Display version for normal operation: Green LED for 24 V OK Output current rated value: 2.5 A Supplied active power typical: 60 W Number of parallel-switched equipment resources for increasing the power: 2 Efficiency in percent: 83 % Power loss [W] at rated output voltage for rated value of the output current typical: 12 W Design of the overvoltage protection: < 33 V Property of the output short-circuit proof: Yes Design of short-circuit protection: Constant current characteristic Galvanic isolation between input and output: Yes Galvanic isolation: Output voltage: SELV, ES1 (IEC 62368-1), DVC As (IEC 61204-7) Operating resource protection class: Class I Protection class IP: IP20 Standard for emitted interference: EN 55022 Class B Standard for interference immunity: EN 61000-6-2 CE marking: Yes UL approval: Yes; cULus-Listed (UL 508, CSA C22.2 No. 107.1), File E197259 UKCA marking: Yes EAC approval: Yes NEC Class 2: Yes; according to UL1310, File E151273 MTBF at 40 °C: 1 492 537 h IECEx: Yes; IECEx Ex nA nC IIC T4 Gc ATEX: Yes; ATEX (EX) II 3G Ex ec nC IIC T4 Gc Shipbuilding approval: Yes American Bureau of Shipping Europe Ltd. (ABS): Yes Det Norske Veritas (DNV): Yes Lloyds Register of Shipping (LRS): Yes Ambient temperature during operation: 0 ... 60 °C; with natural convection Ambient temperature during transport: -40 ... +85 °C Ambient temperature during storage: -40 ... +85 °C Type of electrical connection: screw terminal Connection method — at input: L, N PE: 1 screw terminal each for 0.5 ... 2.5 mm² Connection method — at output: L+ M: 2 screw terminals each for 0.5 ... 2.5 mm² Width × height × depth of the enclosure: 70 × 100 × 75 mm Installation width × mounting height: 70 mm × 140 mm Fastening method: Snaps onto DIN rail EN 60715 35x7.5/15, wall mounting Housing can be lined up: Yes Mechanical data — net weight: 0.3 kg Voltage type (supply voltage): AC 1st secondary output voltage: 24 V Max. output current 1: 2.5 A Secondary voltage adjustable: No Nominal value output voltage 1: 24 V Nominal value output current 1: 2.5 A Short-circuit-proof: Yes Rated supply voltage AC 50 Hz: 230 V Rated supply voltage AC 60 Hz: 120 V Output voltage stabilized: Yes Power output: 60 W Stabilized: Yes Type of electric connection: Screw connection Suitable for rail mounting: Yes Wall mounting possible: Yes Suitable for distribution board: Yes Built-in width: 70 mm Built-in height: 140 mm Direct mounting possible: Yes Width: 70 mm Height: 100 mm Depth: 75 mm Degree of protection (IP): IP20 Suitable for wall mounting: Yes Country of origin: Austria

HS Code

8504.40

• EAN 4025515152446
• SAP 1000096711
• Code 8590205
