Siemens SIRIUS 3RV20 motor protection circuit breaker, frame size S00 3RV2111-1EA10

Siemens 3RV2111-1EA10 — SIRIUS 3RV20 motor protection circuit breaker, frame size S00. Rated 0.11 to 16 A adjustable, up to 100 kA short-circuit breaking, IEC 60947-4-1 type-2 coordination with paired 3RT2 contactor. 11 to 16 A adjustable, up to 100 kA short-circuit breaking, IEC 60947-4-1 type-2 coordination with paired 3RT2 contactor. Motor protection circuit breaker rated current 2.8A-4A.

Manufacturer part number (MPN)

3RV2111-1EA10

EAN / GTIN

4011209713369

HS code

8536.90

Sales unit

pcs

Width

65 mm

Height

97 mm

Depth

97 mm

Rated operation power at AC-3, 400 V

1.5 kW

With integrated auxiliary switch

Yes

Rated permanent current Iu

4 A

With integrated under voltage release

No

Number of poles

3

Rated operating voltage

690 V

Overload release current setting

2.8–4 A

Power loss

7.25 W

Degree of protection (IP)

IP20

With thermal overload protection

Yes

Type of electrical connection of main circuit

Screw connection

Switch off technique

Magnetic

Rated operation power at AC-3, 230 V

0.75 kW

Rated short-circuit breaking capacity Icu at 400 V, AC

100 kA

Adjustment range undelayed short-circuit release

52 A

Phase failure sensitive

Yes

Device construction

Built-in device fixed built-in technique

Country of origin

Germany

HS Code

8536.90
