Siemens 5SM2332-6KK01 RCD Block for MCBs, 3-Pole 40 A 30 mA
Pricing
Request a quote
We reply within 24 hours
Product Description
Siemens 5SM2332-6KK01 is a residual current block for miniature circuit breakers (MCBs), 3-pole, 40 A, 30 mA, short-time delayed and zinc-plated. Type A leakage-current sensing, 4 kA surge current capacity, 400 V nominal voltage and IP20 protection. Suitable for connection to 5SY-series MCBs.
Technical Specifications
- Manufacturer part number (MPN)
- 5SM2332-6KK01
- EAN / GTIN
- 4001869357133
- HS code
- 8536.90
- Sales unit
- pcs
- Nominal voltage
- 400 V
- Nominal current
- 40 A
- Rated fault current adjustable
- No
- Rated fault current
- 30 A
- Delay adjustable
- No
- Number of poles
- 3
- Leakage current type
- A
- Surge current capacity
- 4000 kA
- Frequency
- 50/60 Hz
- Rated insulation voltage Ui
- 460 V
- Rated impulse withstand voltage Uimp
- 3 kV
- Connectable conductor cross section solid-core
- 1.5–25 mm²
- Connectable conductor cross section multi-wired
- 1.5–25 mm²
- Anti-nuisance tripping version
- Yes
- With interlocking device
- No
- Degree of protection (IP)
- IP20
- Pollution degree
- 2
- Ambient temperature during operating
- -25–45 °C
- Country of origin
- Czechia
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 4001869357133
- SAP 1200358518
- Code 82369670
