Schneider GTU Standard Box

Schneider GTU Standard Box. Operator panel (Electrical Engineering / Industry and automation). Supplied under manufacturer part number HMIG2U, EAN 3606489747176, HS code 8537.10, country of origin Indonesia.

Product type

Operator panel

Product group

Industry and automation

REACH SVHC substance above 0.1%

Lead, Diboron-trioxide, Lead-monoxide, Triphenyl phosphate

Carbon footprint (EPD)

12.0097 kg CO2e per pcs

Country of origin

Indonesia

Customs tariff code (EU CN)

85371091

HS code

8537.10

Manufacturer part number

HMIG2U

Range of product

Harmony GTU

Product or component type

Base unit

Device short name

standard box

Range compatibility

Harmony GTU; Allen-Bradley; ABB; MitsubishI; Omron; Siemens

[Us] rated supply voltage

12...24 V DC power supply

Integrated connection type

Ethernet TCP/IP with 2 RJ45; COM1 serial link SUB-D 9 RS232C, transmission rate: 2400...115200 bps; COM2 serial link RJ45 RS485, transmission rate: 187.5 kbps; USB 2.0 port with 2 USB type A; USB 2.0 port mini B USB

Communication port protocol

Modbus; Modbus TCP/IP; Uni-Telway

Software package

Vijeo Designer

Processor name

ARM Cortex-A9

Data storage equipment

1 GB built-in flash memory

Port Ethernet

10BASE-T/100BASE-T

Memory description

256 MB RAM internal (2 x 13 mm board); 512 KB NVRAM backup memory

Number of slots

1 slot(s) for SD card

Realtime clock

Built-in

Local signalling

LED: (steady), green for operating status (RUN); LED: (faded), green for stand-by; LED: (flashing), orange for software starting up; LED: (steady), red for power ON; LED: (alternate), green, orange and red for module error (ERR); LED: (alternate), red/orange for boot status; LED: (alternate), green/red for connection status

Type of cooling

Natural convection

Width

188 mm

Height

131 mm

Depth

45 mm

Product weight

0.9 kg

Standards

CSA C22.2 No 142; ANSI/ISA 12-12-01; UL 508; Class I division 2 CSA C22.2 No 213; IEC 61132-2

Product certifications

CE; CULus; ATEX; IEC-Ex; RCM; GL; KC; CUL; EAC; UKCA; UKEX

Resistance to fast transients

1 kV (signal ports) conforming to IEC 61000-4-4; 2 kV (power ports) conforming to IEC 61000-4-4

Resistance to electrostatic discharge

6 kV contact discharge conforming to IEC 61000-4-2 level 3; 8 kV air discharge conforming to IEC 61000-4-2 level 3

Ambient air temperature for operation

0…60 °C

Ambient air temperature for storage

-20…60 °C

Pollution degree

2 conforming to IEC 61131-2 ed.3

Environmental characteristic

Corrosive gas free

Relative humidity

10…90 % non-condensing

Operating altitude

2000 m

Vibration resistance

3.5 mm constant amplitude (f = 5…9 Hz) X, Y, Z directions for 10 cycles (approx. 100 min) conforming to IEC 61131-2; 9.8 m/s² (f = 9…150 Hz) X, Y, Z directions for 10 cycles (approx. 100 min) conforming to IEC 61131-2

Shock resistance

147 m/s² (X, Y, Z directions for 3 times) conforming to IEC 61131-2

Electromagnetic compatibility

Electrostatic discharge immunity test level 3 conforming to IEC 61000-4-2

Number of Units in Package 1

1

Number of Units in Package 2

4

Warranty (in months)

18

EAN

3606489747176

HS Code

8537.10
