Schneider ACTI9 C120 Vigi Residual current circuit breaker PFI - ACTI9 C120, 125A, 2P, Asi, 300MA
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Acti9 C120 Vigi Residual current circuit breaker PFI. Residual current devices (RCD, PFI, Combo) (Electrical Engineering / Components for panels and boxes). Principal data: series Acti9 C120, current rating 125 A, number of poles 2P, class Asi. Supplied under manufacturer part number A9N18556, EAN 3606480376597, HS code 8536.30, country of origin France.
Technical Specifications
- Product type
- Residual current devices (RCD, PFI, Combo)
- Product group
- Components for panels and boxes
- Series
- Acti9 C120
- Current rating
- 125 A
- Number of poles
- 2P
- Class
- Asi
- Rated residual current
- 300 mA
- REACH SVHC substance above 0.1%
- Lead, Diboron-trioxide, Lead tetroxide, Lead-monoxide, Octrizole, Triphenyl phosphate
- Carbon footprint (EPD)
- 2.2533 kg CO2e per pcs
- Country of origin
- France
- Customs tariff code (EU CN)
- 85363030
- HS code
- 8536.30
- Manufacturer part number
- A9N18556
- GTIN (EAN)
- 3606480376597
- Range
- Acti9
- Product name
- Acti9 Vigi C120
- Product or component type
- Add-on residual current device
- Device short name
- Vigi C120
- Poles description
- 2P
- [In] rated current
- 125 A
- Network type
- AC
- Earth-leakage sensitivity
- 300 mA
- Earth-leakage protection time delay
- Selective
- Earth-leakage protection class
- Type A-SI (Super Immunised)
- Standards
- EN 61009; IEC/EN 61009-2-1
- Device location in system
- Outgoer; Group incomer
- Network frequency
- 50 Hz
- [Ue] rated operational voltage
- 230...415 V AC 50 Hz
- Residual current tripping technology
- Voltage independent
- [Ui] rated insulation voltage
- 500 V AC 50/60 Hz conforming to IEC 60947-1
- [Uimp] rated impulse withstand voltage
- 6 kV conforming to IEC 60947-2
- mounting mode
- Clip-on
- Mounting support
- 35 mm symmetrical DIN rail
- Electrical connection to mcb
- By screws
- 9 mm pitches
- 7
- Height
- 95 mm
- Width
- 117 mm
- Depth
- 73 mm
- Product weight
- 0.325 kg
- Colour
- White
- Mechanical durability
- 20000 cycles
- Connections - terminals
- Tunnel type terminals 1…35 mm² flexible; Tunnel type terminals 1…50 mm² rigid
- Wire stripping length
- 15 mm
- Tightening torque
- 3.5 N.m
- IP degree of protection
- IP20
- Pollution degree
- 3 conforming to IEC 60947-2
- Ambient air temperature for operation
- -25…60 °C
- Ambient air temperature for storage
- -40…60 °C
- Warranty (in months)
- 18
