Schneider Electric current transformer TeSys T LT6CT - 100/1 A - accuracy: class 5P LT6CT1001
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric LT6CT1001.
Technical Specifications
- Manufacturer part number (MPN)
- LT6CT1001
- EAN / GTIN
- 3389110943269
- Sales unit
- pcs
- Range
- TeSys
- Device short name
- LT6CT
- Product or component type
- Current transformer
- Range compatibility
- TeSys TeSys T motor controller
- Current transformer ratio
- 100/1
- Accuracy class
- Class 5P
- Precision limit factor
- 15
- [Ui] rated insulation voltage
- 690 V
- Diameter
- 35 mm
- Cable cross section
- 30 mm²
- Height
- 107 mm
- Width
- 95 mm
- Depth
- 25 mm
- Product weight
- 0.55 kg
- Standards
- IEC 60185; BS 7626
- Maximum ambient air temperature for operation
- 50 °C
- Unit Type of Package 1
- PCE
- Number of Units in Package 1
- 1
- Package 1 Height
- 3.100 cm
- Package 1 Width
- 12.500 cm
- Package 1 Length
- 10.600 cm
- Package 1 Weight
- 540.000 g
- Unit Type of Package 2
- S02
- Number of Units in Package 2
- 20
- Package 2 Height
- 15.000 cm
- Package 2 Width
- 30.000 cm
- Package 2 Length
- 40.000 cm
- Package 2 Weight
- 11.050 kg
- Country of origin
- GB
- Warranty (in months)
- 18
- Model
- Through-feed current converter
- Rated primary current
- 100 A
- Rated secondary current
- 1 A
- Calibrated
- No
- With contact protection
- No
- Height opening
- 107 mm
- Width opening
- 95 mm
- Opening diameter
- 35 mm
- Snap mounting
- No
- With copper rail
- No
- Number of primary inputs
- 1
- Secondary connection
- Screw connection
Standards & Compliance
- HS Code
- 8504.31
Cross References
- EAN 3389110943269
- SAP 1000026419
- Code 8238266
