Schneider Electric NSYOPB18U5FR Actassi OPB 19in Wall-Mount Cabinet 18U 600x500

Schneider Electric NSYOPB18U5FR is an Actassi OPB 19 inch wall-mount open-frame cabinet with 18 rack units of height, 600 mm wide and 500 mm deep. Two fixed 19 inch uprights are set back 120 mm from the front on a 25 mm pitch; the removable plain front door has a single-point lock (key 333) with reversible 180 degree opening. Sheet-steel construction with epoxy-polyester powder finish in light grey (RAL 7035), IP20 and IK10. Load rating 50 kg static.

Manufacturer part number (MPN)

NSYOPB18U5FR

EAN / GTIN

3606480287640

Sales unit

pcs

Package quantity

2 pcs

Range

Actassi

Product name

Actassi OPB

Product or component type

19" enclosure

Device application

Cabling

applications

To improve security of the equipment; To mount 19" equipment; To protect network connectivity equipment

enclosure type

Open box

support equipment

2 x fixed 19" uprights recessed of 120 mm from the front (pitch 25 mm)

front face

Plain door

Door type

Front plain door - with 1 point locking system (key: 333) - reversible opening at 180 °

Accessibility for operation

Side; Rear; Front

Removable parts

Front door removable toolless; Top blanking plate; Bottom blanking plate; Rear blanking plate; Side panels removable toolless

colour

Light grey (RAL 7035)

Device composition

3 x cable entries; 2 x panels side; 2 x 19" uprights front; 1 x open structure; 1 x plain door front

load rating

50 kg static; 3 kg by unit

back face

Cut-out

side face

Panel

Number of cut-out

1 cut-outside; 1 cut-outbottom; 1 cut-outtop

installation mode

Wall mounted

Material

Sheet steel: structure; Sheet steel: door; Galvanized steel: upright

Surface finish

Epoxy-polyester powder

Width

600 mm

Height

915 mm

Depth

500 mm

Product weight

30.25 kg

Number of rack unit

18U

Targeted region

Europe

IK degree of protection

IK10 conforming to IEC 62262

IP degree of protection

IP20 conforming to IEC 60529

Standards

EIA-310D; IEC 60297-3-100

Number of Units in Package 1

1

Number of Units in Package 2

2

Warranty (in months)

18

Mounting level

Front and rear

Model

With permanent frame

Type of profile rail

None

Number of doors

1

Type of ventilation

None

Number of height units

18

Max. load capacity

50 kg

With roof plate

Yes

With earthing

No

With front door

Yes

With sidewall

Yes

Demountable

Yes

Surface finishing

Powder coating

RAL-number

7035

Degree of protection (IP)

IP20

Country of origin

Romania

HS Code

9403.20
