Schneider Electric WDE002391 Exxact Low-Voltage Push-Button 1K with LED

Schneider Electric WDE002391 is a flush-mounted Exxact low-voltage push-button rocker with a single make contact (NO), integrated LED illumination and a 24 V rated coil, in white halogen-free thermoplastic. Designed for screw-terminal wiring in a standard 35 mm deep installation box, it provides momentary control for bell, door-release and lighting applications with visible illumination when active. Rated 0.4 A with IP20 protection and IK02 impact resistance.

Manufacturer part number (MPN)

WDE002391

EAN / GTIN

3606480206962

Sales unit

pcs

Nominal voltage

24 V

Mounting method

Flush-mounted

Assembly arrangement

Basic element with central cover plate

Method of operation

Push button

Colour

White

Model

Single push button

Halogen free

Yes

Contacts

1 make contact (NO)

Connection type

Screwed terminal

Imprint

None

Surface protection

Untreated

With signal lamp

Yes

Rated current

0.4 A

Label space/information surface

No

Monitoring contact

No

Material quality

Thermoplastic

Number of poles

1

Material

Plastic

Type of fastening

Screw mounting

Number of rockers

1

With lighting

Yes

RAL-number (similar)

9003

Impact strength

IK02

With light source

Yes

Transparent

No

Surface finishing

Glossy

Suitable for degree of protection (IP)

IP20

Number of contacts as normally open contact

1

Device width

71 mm

Device height

71 mm

Device depth

39 mm

IFTTT support available

No

Min. depth of built-in installation box

35 mm

Compatible with Apple HomeKit

No

Compatible with Google Assistant

No

Compatible with Amazon Alexa

No

Contactless type

No

Anti-bacterial treatment

No

Country of origin

Finland

HS Code

8536.50

• EAN 3606480206962
• SAP 1000093952
• Code 8587061
