Zelio Logic UTV. 2AI/2AO 24VDC

Schneider Electric SR3XT43BD Zelio external. 2/2 In/O analoge.

Manufacturer part number (MPN)

SR3XT43BD

EAN / GTIN

3389119203968

Sales unit

pcs

Package quantity

48 pcs

Voltage

24 V DC

Range of product

Zelio Logic

Product or component type

Analogue I/O extension module

Analogue input number

2

Analogue input type

Common mode

Analogue input range

0...10 V; 0...20 mA; -25...125 °C

Temperature probe type

Pt 100, 3-wire conforming to IEC 751

Maximum permissible voltage

30 V for analogue input circuit

[Imp] maximum permanent current

30 mA for analogue input circuit

Analogue input resolution

10 bits on the input range

Input impedance

18 kOhm, input range: 0...10 V for analogue input circuit; 247 Ohm, input range: 0...20 mA for analogue input circuit

Analogue output number

2

Analogue output range

0...10 V

Analogue output resolution

10 bits on the output range

Load type

Resistive load for analogue output

Maximum load current

10 mA for analogue output

Short-circuit protection

With analogue output

LSB value

0.15 °C, - 25...125 °C for analogue input circuit; 20 µA, 0...20 mA for analogue input circuit; 9.8 mV, 0...10 V for analogue input circuit; 9.8 mV, 0...10 V for analogue output

Conversion time

Smart relay cycle time for analogue input circuit; Smart relay cycle time for analogue output

Conversion error

+/- 1 % of the full scale value, input range: 0...10 V (25 °C) for analogue output; +/- 1 % of the full scale value, input range: 0...10 V (55 °C) for analogue output; +/- 1 %, input range: 0...10 V (25 °C) for analogue input circuit; +/- 1 %, input range: 0...10 V (55 °C) for analogue input circuit; +/- 1 %, input range: 0...20 mA (25 °C) for analogue input circuit; +/- 1 %, input range: 0...20 mA (55 °C) for analogue input circuit; +/- 1.5 °C, input range: - 25...125 °C (25 °C) for analogue input circuit; +/- 1.5 °C, input range: - 25...125 °C (55 °C) for analogue input circuit

Repeat accuracy

< +/- 0.3 °C, input range: - 25...125 °C at 25 °C for analogue input circuit; <= +/- 1 %, input range: 0...10 V at 25 °C for analogue input circuit; <= +/- 1 %, input range: 0...10 V at 55 °C for analogue output; <= +/- 1 %, input range: 0...20 mA at 25 °C for analogue input circuit

Operating distance

10 m with screened cable for analogue input circuit; 10 m with screened cable for analogue output

Reverse polarity protection

Analogue input circuit: with

Connections - terminals

Screw terminals, 1 x 0.25...1 x 2.5 mm² (24 AWG...14 AWG) semi-solid; Screw terminals, 1 x 0.25...1 x 2.5 mm² (24 AWG...14 AWG) solid; Screw terminals, 2 x 0.25...2 x 1.5 mm² (23 AWG...16 AWG) solid; Screw terminals, 1 x 0.25...1 x 2.5 mm² (24 AWG...14 AWG) flexible with cable end; Screw terminals, 2 x 0.25...2 x 0.75 mm² (24 AWG...18 AWG) flexible with cable end

Tightening torque

0.5 N.m

Product weight

0.11 kg

Product certifications

GOST; UL; C-Tick; CSA

Standards

IEC 61000-4-12; IEC 61000-4-5; IEC 61000-4-3; IEC 61000-4-4 level 3; IEC 61000-4-6 level 3; IEC 61000-4-2 level 3; IEC 60068-2-6 Fc; IEC 61000-4-11; IEC 60068-2-27 Ea

IP degree of protection

IP20 (terminal block) conforming to IEC 60529; IP40 (front panel) conforming to IEC 60529

Environmental characteristic

EMC directive conforming to IEC 61000-6-2; EMC directive conforming to IEC 61000-6-3; EMC directive conforming to IEC 61000-6-4; EMC directive conforming to IEC 61131-2 zone B; Low voltage directive conforming to IEC 61131-2

Disturbance radiated/conducted

Class B conforming to IEC 55022-11 Group 1

Pollution degree

2 conforming to IEC 61131-2

Ambient air temperature for operation

-20…40 °C conforming to IEC 60068-2-1 and IEC 60068-2-2; -20…55 °C conforming to IEC 60068-2-1 and IEC 60068-2-2

Ambient air temperature for storage

-40…70 °C

Operating altitude

2000 m

Maximum altitude transport

3048 m

Relative humidity

95 % without condensation or dripping water

Number of Units in Package 1

1

Number of Units in Package 2

48

Country of origin

FR

Warranty (in months)

18

Power consumption

1.1 W

Certified for UL hazardous location division 1

No

Certified for UL hazardous location division 2

No

Certified for UL hazardous location group A (acetylene)

No

Certified for UL hazardous location group B (hydrogen)

No

Certified for UL hazardous location group C (ethylene)

No

Certified for UL hazardous location group D (propane)

No

Certified for UL hazardous location group E (metal dusts)

No

Certified for UL hazardous location class I

No

Certified for UL hazardous location class II

No

Certified for UL hazardous location class III

No

Supporting protocol for EtherCAT

No

Supply voltage DC

24 V

Voltage type (supply voltage)

DC

Switching current

0.02 A

Number of analogue inputs

2

Number of analogue outputs

1

With relay output

No

With optical interface

No

Supporting protocol for TCP/IP

No

Supporting protocol for PROFIBUS

No

Supporting protocol for CAN

No

Supporting protocol for INTERBUS

No

Supporting protocol for ASI

No

Supporting protocol for KNX

No

Supporting protocol for Modbus

No

Supporting protocol for Data-Highway

No

Supporting protocol for DeviceNet

No

Supporting protocol for SUCONET

No

Supporting protocol for LON

No

Supporting protocol for PROFINET IO

No

Supporting protocol for PROFINET CBA

No

Supporting protocol for SERCOS

No

Supporting protocol for Foundation Fieldbus

No

Supporting protocol for EtherNet/IP

No

Supporting protocol for AS-Interface Safety at Work

No

Supporting protocol for DeviceNet Safety

No

Supporting protocol for INTERBUS-Safety

No

Supporting protocol for PROFIsafe

No

Supporting protocol for SafetyBUS p

No

Supporting protocol for other bus systems

No

Radio standard Bluetooth

No

Radio standard WLAN 802.11

No

Radio standard GPRS

No

Radio standard GSM

No

Mobile communications standard 3G (UMTS)

No

IO link master

No

Redundancy

No

With display

No

Degree of protection (IP)

IP20

Basic device

Yes

Expandable

No

Expansion device

Yes

With time switch clock

No

Suitable for rail mounting

Yes

Wall mounting/direct mounting

Yes

Front built-in possible

Yes

Rack-assembly possible

No

Suitable for safety functions

No

SIL according to IEC 61508

None

Performance level according to EN ISO 13849-1

None

Appendant operation agent (Ex ia)

No

Explosion safety category for gas

None

Explosion safety category for dust

None

Width

35 mm

Height

90 mm

Depth

59.5 mm

HS Code

8538.90

• EAN 3389119203968
• SAP 1000082572
• Code 8574541
