Schneider Electric BMXNOM0200 Serial link module with 2 RS-485/232 ports in Modbus and Character mode
Pricing
Request a quote
We reply within 24 hours
Overview
Schneider Electric BMXNOM0200 Serial link module with 2 RS-485/232 ports in Modbus and Character mode is listed under Electrical Components / Contactor Accessories. Sales unit: pcs; Package quantity: 15 pcs; Range of product: Modicon X80; Product or component type: Serial links module; Concept: Serial link; Protective treatment: TC.
Technical Specifications
- Manufacturer part number (MPN)
- BMXNOM0200
- EAN / GTIN
- 3595864024431
- Sales unit
- pcs
- Package quantity
- 15 pcs
- Range of product
- Modicon X80
- Product or component type
- Serial links module
- Concept
- Serial link
- Integrated connection type
- RS232 RJ45 115.2 kbit/s 8 wires; RS485 RJ45 57.6 kbit/s 1 twisted pair
- Protective treatment
- TC
- Supply
- Internal power supply via rack
- Marking
- CE
- Local signalling
- 1 LED (red) for module fault (ERR); 1 LED (green) for module running (RUN); 1 LED (green) for activity on the serial link (SER COM 0); 1 LED (green) for activity on the serial link (SER COM 1)
- Current consumption
- 80 mA at 24 V DC
- Module format
- Standard
- Product weight
- 0.23 kg
- Ambient air temperature for operation
- 0…60 °C
- Relative humidity
- 10…95 % without condensation
- IP degree of protection
- IP20
- Directives
- 2014/35/EU - low voltage directive; 2014/30/EU - electromagnetic compatibility
- Unit Type of Package 1
- PCE
- Number of Units in Package 1
- 1
- Package 1 Height
- 5.300 cm
- Package 1 Width
- 11.700 cm
- Package 1 Length
- 12.000 cm
- Package 1 Weight
- 217.000 g
- Unit Type of Package 2
- S02
- Number of Units in Package 2
- 15
- Package 2 Height
- 15.000 cm
- Package 2 Width
- 30.000 cm
- Package 2 Length
- 40.000 cm
- Package 2 Weight
- 3.600 kg
- Unit Type of Package 3
- P06
- Number of Units in Package 3
- 240
- Package 3 Height
- 75.000 cm
- Package 3 Width
- 60.000 cm
- Package 3 Length
- 80.000 cm
- Package 3 Weight
- 65.940 kg
- Country of origin
- FR
- Warranty (in months)
- 18
- Power consumption
- 1.1 W
- Certified for UL hazardous location division 1
- No
- Certified for UL hazardous location division 2
- No
- Certified for UL hazardous location group A (acetylene)
- No
- Certified for UL hazardous location group B (hydrogen)
- No
- Certified for UL hazardous location group C (ethylene)
- No
- Certified for UL hazardous location group D (propane)
- No
- Certified for UL hazardous location group E (metal dusts)
- No
- Certified for UL hazardous location class I
- No
- Certified for UL hazardous location class II
- No
- Certified for UL hazardous location class III
- No
- Supporting protocol for EtherCAT
- No
- Number of HW-interfaces RS-232
- 1
- Number of HW-interfaces RS-485
- 1
- With optical interface
- No
- Supporting protocol for TCP/IP
- No
- Supporting protocol for PROFIBUS
- No
- Supporting protocol for CAN
- No
- Supporting protocol for INTERBUS
- No
- Supporting protocol for ASI
- No
- Supporting protocol for KNX
- No
- Supporting protocol for Modbus
- Yes
- Supporting protocol for Data-Highway
- No
- Supporting protocol for DeviceNet
- No
- Supporting protocol for SUCONET
- No
- Supporting protocol for LON
- No
- Supporting protocol for PROFINET IO
- No
- Supporting protocol for PROFINET CBA
- No
- Supporting protocol for SERCOS
- No
- Supporting protocol for Foundation Fieldbus
- No
- Supporting protocol for EtherNet/IP
- No
- Supporting protocol for AS-Interface Safety at Work
- No
- Supporting protocol for DeviceNet Safety
- No
- Supporting protocol for INTERBUS-Safety
- No
- Supporting protocol for PROFIsafe
- No
- Supporting protocol for SafetyBUS p
- No
- Supporting protocol for other bus systems
- No
- Radio standard Bluetooth
- No
- Radio standard WLAN 802.11
- No
- Radio standard GPRS
- No
- Radio standard GSM
- No
- Mobile communications standard 3G (UMTS)
- No
- IO link master
- No
- Redundancy
- No
- Type of data transmission
- Module rack extension
- Transmission rate
- 115.2 kBit/s
- With potential separation
- Yes
- SIL according to IEC 61508
- None
- Suitable for safety functions
- No
- Performance level according to EN ISO 13849-1
- None
- Appendant operation agent (Ex ia)
- No
- Explosion safety category for gas
- None
- Explosion safety category for dust
- None
- Width
- 29 mm
- Height
- 100 mm
- Depth
- 160 mm
Standards & Compliance
- HS Code
- 8517.62
Cross References
- EAN 3595864024431
- SAP 1000012807
- Code 899316
Product Documentation
