Schneider Electric distributed analog output Modicon Momentum - 4 Output - 4..20 mA 170AAO92100

Schneider Electric distributed analog output Modicon Momentum - 4 Output - 4..20 mA 170AAO92100 is listed under Control & Automation / PLCs & Industrial Networking. Sales unit: pcs; Package quantity: 10 pcs; Output signal: 4–20 mA; Range of product: Modicon Momentum automation platform; Product or component type: Analogue output base; Analogue output number: 4.

Manufacturer part number (MPN)

170AAO92100

EAN / GTIN

3595861147720

Sales unit

pcs

Package quantity

10 pcs

Output signal

4–20 mA

Range of product

Modicon Momentum automation platform

Product or component type

Analogue output base

Analogue output number

4

Data format

Full 16 bits signed

Analogue output range

+/- 10 V 12 bits + sign >= 1 kOhm; 4...20 mA 12 bits + sign <= 0.6 kOhm

Maximum load capacitance

1 µF

Absolute accuracy error

+/- 0.2 % of full scale +/- 10 V 25 °C; +/- 0.25 % full scale +/- 10 V 60 °C; +/- 0.4 % of full scale 4...20 mA 25 °C; +/- 0.5 % of full scale 4...20 mA 60 °C

Update time

2 ms

Full scale

10 V +/- 10 V; 2 mA 4...20 mA

Fail state

Hold; Reset to full scale; Reset to zero

Protection type

Internal 2 A slow-blow

Output short-circuit protection

With in voltage circuit

External power requirement

+/- 30 V DC; 24 V DC

Permissible common mode voltage

250 V 47...63 Hz AC between channels to ground; 250 V 47...63 Hz DC

Reverse polarity protection

Internal

Module format

Standard

Temperature drift

10 %oFS/°C; 30 %oFS/°C

Typical current consumption

150 mA at 24 V DC; 530 mA at 24 V DC

Power dissipation in W

8.5 W

Isolation between channels and ground

500 V AC

Local signalling

4 LEDs for channel status

Height

125 mm

Width

141.5 mm

Depth

47.5 mm

Product weight

0.215 kg

Protective treatment

TC

Marking

CE

Product certifications

UL; CSA

Ambient air temperature for operation

0…60 °C

Ambient air temperature for storage

-40…85 °C

Relative humidity

95 % without condensation

Operating altitude

<= 5000 m

Number of Units in Package 1

1

Number of Units in Package 2

10

Number of Units in Package 3

80

Country of origin

ID

Warranty (in months)

18

Power consumption

8.5 W

Certified for UL hazardous location division 1

No

Certified for UL hazardous location division 2

No

Certified for UL hazardous location group A (acetylene)

No

Certified for UL hazardous location group B (hydrogen)

No

Certified for UL hazardous location group C (ethylene)

No

Certified for UL hazardous location group D (propane)

No

Certified for UL hazardous location group E (metal dusts)

No

Certified for UL hazardous location class I

No

Certified for UL hazardous location class II

No

Certified for UL hazardous location class III

No

Supporting protocol for EtherCAT

No

Supply voltage DC

24 V

Voltage type (supply voltage)

DC

Input, current

No

Input, voltage

No

Input, resistor

No

Input, resistance thermometer

No

Input, thermocouple

No

Input signal, configurable

No

Output, current

Yes

Output, voltage

Yes

Output signal configurable

Yes

Resolution of the analogue outputs

12 Bit

Number of analogue outputs

4

Analogue inputs configurable

No

Analogue outputs configurable

Yes

Supporting protocol for TCP/IP

No

Supporting protocol for PROFIBUS

No

Supporting protocol for CAN

No

Supporting protocol for INTERBUS

No

Supporting protocol for ASI

No

Supporting protocol for KNX

No

Supporting protocol for Modbus

No

Supporting protocol for Data-Highway

No

Supporting protocol for DeviceNet

No

Supporting protocol for SUCONET

No

Supporting protocol for LON

No

Supporting protocol for PROFINET IO

No

Supporting protocol for PROFINET CBA

No

Supporting protocol for SERCOS

No

Supporting protocol for Foundation Fieldbus

No

Supporting protocol for EtherNet/IP

No

Supporting protocol for AS-Interface Safety at Work

No

Supporting protocol for DeviceNet Safety

No

Supporting protocol for INTERBUS-Safety

No

Supporting protocol for PROFIsafe

No

Supporting protocol for SafetyBUS p

No

Supporting protocol for other bus systems

No

Radio standard Bluetooth

No

Radio standard WLAN 802.11

No

Radio standard GPRS

No

Radio standard GSM

No

Mobile communications standard 3G (UMTS)

No

IO link master

No

System accessory

No

Fieldbus connection over separate bus coupler possible

No

Suitable for rail mounting

No

Wall mounting/direct mounting

No

Front built-in possible

No

Rack-assembly possible

No

Suitable for safety functions

No

SIL according to IEC 61508

None

Performance level according to EN ISO 13849-1

None

Appendant operation agent (Ex ia)

No

Explosion safety category for gas

None

Explosion safety category for dust

None

HS Code

8538.90
