Schneider Electric discrete input module Modicon Momentum - 16 Input 24 V DC 170ADI34000
Pricing
Request a quote
We reply within 24 hours
Overview
Schneider Electric discrete input module Modicon Momentum - 16 Input 24 V DC 170ADI34000 is listed under Control & Automation / I/O Modules. Sales unit: pcs; Package quantity: 10 pcs; Voltage: 24 V DC; Range of product: Modicon Momentum automation platform; Product or component type: Discrete inputs base DC; Group of channels: 1 group of 16 inputs.
Technical Specifications
- Manufacturer part number (MPN)
- 170ADI34000
- EAN / GTIN
- 3595861000247
- Sales unit
- pcs
- Package quantity
- 10 pcs
- Voltage
- 24 V DC
- Range of product
- Modicon Momentum automation platform
- Product or component type
- Discrete inputs base DC
- Group of channels
- 1 group of 16 inputs
- Discrete input number
- 16
- Discrete input logic
- Positive
- Voltage range
- - 3...30 V
- Isolation between channels and bus
- 500 V AC
- Terminals description PLC n°1
- (8)IN_DIS#8; (5)IN_DIS#5; (16)IN_DIS#16; (4)IN_DIS#4; (3)IN_DIS#3; (13)IN_DIS#13; (14)IN_DIS#14; (10)IN_DIS#10; (L+)PW_POS; (M-)PW_NEG; (6)IN_DIS#6; (7)IN_DIS#7; (1)IN_DIS#1; (11)IN_DIS#11; (9)IN_DIS#9; (15)IN_DIS#15; (12)IN_DIS#12; TB; (2)IN_DIS#2
- Local signalling
- 16 LEDs for channel status
- Height
- 141.5 mm
- Width
- 125 mm
- Depth
- 47.5 mm
- Product weight
- 0.19 kg
- Protective treatment
- TC
- Marking
- CE
- Number of Units in Package 1
- 1
- Number of Units in Package 2
- 10
- Country of origin
- ID
- Warranty (in months)
- 18
- Supply voltage DC
- 24 V
- Voltage type (supply voltage)
- DC
- Number of digital inputs
- 16
- Digital inputs configurable
- No
- Digital outputs configurable
- No
- Input current at signal 1
- 2.5 mA
- Permitted voltage at input
- -3–30 V
- Type of voltage (input voltage)
- AC/DC
- Type of digital output
- None
- Type of output voltage
- AC/DC
- Short-circuit protection, outputs available
- No
- Redundancy
- No
- Type of electric connection
- Screw connection
- Time delay at signal change
- 3.3 ms
- Suitable for safety functions
- No
- SIL according to IEC 61508
- None
- Performance level according to EN ISO 13849-1
- None
- Appendant operation agent (Ex ia)
- No
- Explosion safety category for gas
- None
- Explosion safety category for dust
- None
Standards & Compliance
- HS Code
- 8538.90
Cross References
- EAN 3595861000247
- SAP 1000023290
- Code 8185867
