Schneider Electric MN undervoltage release, ComPacT NSX, rated voltage 30 VDC, screwless spring terminal connections LV429411
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric LV429411 MN 30VDC nullsp.coil =NSX630.
Technical Specifications
- Manufacturer part number (MPN)
- LV429411
- EAN / GTIN
- 3606480019005
- Sales unit
- pcs
- Package quantity
- 10 pcs
- Range
- ComPacT
- Range of product
- ComPact NSX100...250; ComPacT NSX100...250; ComPact NSX400...630; ComPacT NSX400...630; ComPact NSX100...250 DC; ComPacT NSX100...250 DC; ComPact NSX100...250 DC PV; ComPacT NSX100...250 DC PV; ComPact NSX400...630 DC; ComPacT NSX400...630 DC; ComPact NSX400...630 DC PV; ComPacT NSX400...630 DC PV
- Device short name
- MN
- Product or component type
- Voltage release
- Device application
- Control
- Voltage release type
- Opening coil; Undervoltage release
- [Uc] control circuit voltage
- 30 V DC
- Range compatibility
- ComPacT ComPacT NSX; ComPacT ComPacT NSX DC; ComPact ComPact NSX; ComPact ComPact NSX DC; EasyPact EasyPact CVS; PowerPact PowerPact Multistandard
- Operating threshold
- 0.35...0.7 x Un opening; 0.85 x Un closing
- Response time
- 50 ms
- Supply holding power
- 5 W
- Supply inrush power
- 10 W
- Auxiliary connection terminal
- Spring 0.5…1.5 mm² (20 AWG...16 AWG)
- Wire stripping length
- 7 mm
- Unit Type of Package 1
- PCE
- Number of Units in Package 1
- 1
- Package 1 Height
- 3.8 cm
- Package 1 Width
- 6.3 cm
- Package 1 Length
- 8.2 cm
- Package 1 Weight
- 135 g
- Unit Type of Package 2
- BB1
- Number of Units in Package 2
- 10
- Package 2 Height
- 8.8 cm
- Package 2 Width
- 14.3 cm
- Package 2 Length
- 22.5 cm
- Package 2 Weight
- 1.434 kg
- Unit Type of Package 3
- S03
- Number of Units in Package 3
- 60
- Package 3 Height
- 30 cm
- Package 3 Width
- 30 cm
- Package 3 Length
- 40 cm
- Package 3 Weight
- 9.044 kg
- Country of origin
- PL
- Warranty (in months)
- 18
- Delayed
- No
- Suitable for off-load switch
- Yes
- Suitable for overload relay
- No
- Type of electric connection
- Spring clamp connection
- Rated control supply voltage DC
- 30 V
- Suitable for motor safety switch
- Yes
- Suitable for power circuit breaker
- Yes
- Voltage type for actuating
- DC
Standards & Compliance
- HS Code
- 8536.30
Cross References
- EAN 3606480019005
- SAP 1000092310
- Code 8585034
