Schneider Electric MN undervoltage release, ComPacT NSX, rated voltage 380/415 VAC 50/60 Hz, 440/480 VAC 60 Hz, screwless spring terminal connections LV429408
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric LV429408 MN 380-415V50Hz 440-480V 60Hz.
Technical Specifications
- Manufacturer part number (MPN)
- LV429408
- EAN / GTIN
- 3606480018978
- Sales unit
- pcs
- Package quantity
- 10 pcs
- Voltage
- 440-480 V
- Frequency
- 60 Hz
- Range
- ComPacT
- Range of product
- ComPact NSX100...250; ComPacT NSX100...250; ComPact NSX400...630; ComPacT NSX400...630; ComPact NSX100...250 DC; ComPacT NSX100...250 DC; ComPact NSX100...250 DC PV; ComPacT NSX100...250 DC PV; ComPact NSX400...630 DC; ComPacT NSX400...630 DC; ComPact NSX400...630 DC PV; ComPacT NSX400...630 DC PV
- Device short name
- MN
- Product or component type
- Voltage release
- Device application
- Control
- Voltage release type
- Opening coil; Undervoltage release
- [Uc] control circuit voltage
- 380...415 V AC 50 Hz; 440...480 V AC 60 Hz
- Range compatibility
- ComPacT ComPacT NSX; ComPacT ComPacT NSX DC; ComPact ComPact NSX; ComPact ComPact NSX DC; EasyPact EasyPact CVS; PowerPact PowerPact Multistandard
- Operating threshold
- 0.35...0.7 x Un opening; 0.85 x Un closing
- Response time
- 50 ms
- Supply holding power
- 5 VA
- Supply inrush power
- 10 VA
- Auxiliary connection terminal
- Spring 0.5…1.5 mm² (20 AWG...16 AWG)
- Wire stripping length
- 7 mm
- Country of origin
- PL
- Warranty (in months)
- 18
- Delayed
- No
- Suitable for off-load switch
- Yes
- Suitable for overload relay
- No
- Type of electric connection
- Spring clamp connection
- Rated control supply voltage AC 50 Hz
- 380–415 V
- Rated control supply voltage AC 60 Hz
- 440–480 V
- Suitable for motor safety switch
- Yes
- Suitable for power circuit breaker
- Yes
- Voltage type for actuating
- AC
Standards & Compliance
- HS Code
- 8536.30
Cross References
- EAN 3606480018978
- SAP 1000092307
- Code 8585031
Product Documentation
More from Schneider Electric
Schneider Electric
GNISTK.Cover NS630B-1600 3P
33596
Schneider Electric
Schneider Electric Push-button Pro T, Merten System M, active white, Temperature sensor, Touchless, Supply KNX 20 mA MTN6185-0325
Schneider Electric
Schneider Electric ZB4BH033 Harmony XB4 Push-Button Head — Ø22 mm, Green, flush, push-push, illuminated (LED), metal bezel
Schneider Electric
Schneider Electric UFB-IG Cast-In Floor Box 110/150 mm
5197565
Schneider Electric
Schneider Electric reversing Contactor, TeSys K, 3P, AC-3/AC-3E,<=440V 9A, 1NC, 24V AC coil LC2K0901B7
Schneider Electric
Schneider Electric XACA08 empty pendant control station XAC-A - 8 vertical openings
Schneider Electric
Schneider Electric ZA2BD2 black selector switch - 2 positions - standard handle
Schneider Electric
Schneider Electric plug-in kit, ComPact NSX 400/630, 4 poles LV432539
Technical guides
Catalogue entry last verified: 2026-09-29. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy LV429408?
- LV429408 can be ordered from cballast.com as a Schneider Electric catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Schneider Electric product?
- The manufacturer part number is LV429408.
- What is the HS code for LV429408?
- The customs tariff (HS) code for LV429408 is 8536.30.
- Who manufactures LV429408?
- LV429408 is a Schneider Electric product in the Electrical Components range.
- Is a datasheet available for LV429408?
- Yes — the LV429408 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for LV429408?
- The minimum order quantity is 1.
- Is LV429408 available?
- Yes — LV429408 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
