Schneider Electric Trip unit MA2.5, ComPacT NSX100, 3 poles, magnetic protections, motor protection, 2.5A rating C103MA003
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric C103MA003 Short-circuit protection for ComPacT NSX circuit breaker MA2.5 3P3T 2.5A.
Technical Specifications
- Manufacturer part number (MPN)
- C103MA003
- EAN / GTIN
- 3606482000308
- HS code
- 8536.90
- Sales unit
- pcs
- Package quantity
- 28 pcs
- Range
- ComPacT
- Range of product
- ComPacT NSX100...250
- Product or component type
- Trip unit
- Trip unit name
- MA
- Trip unit technology
- Magnetic
- Range compatibility
- ComPacT NSX100
- Device application
- Motor
- Poles description
- 3P
- Protected poles description
- 3D
- Trip unit protection functions
- I
- Protection type
- I : for short-circuit protection (magnetic)
- Trip unit rating
- 2.5 A at 65 °C
- [Ue] rated operational voltage
- 690 V AC 50/60 Hz
- Network type
- AC
- Network frequency
- 50/60 Hz
- Circuit breaker mounting mode
- Fixed
- Instantaneous protection pick-up adjustment type Ii
- Adjustable 9 settings
- [Ii] instantaneous protection pick-up adjustment range
- 6...14 x In
- Earth-leakage protection
- Without
- Standards
- EN/IEC 60947-2
- Electrical shock protection class
- Class II
- Pollution degree
- 3 conforming to IEC 60947-1
- IP degree of protection
- IP40 conforming to IEC 60529
- Ambient air temperature for operation
- -25…70 °C
- Ambient air temperature for storage
- -50…85 °C
- Number of Units in Package 1
- 1
- Number of Units in Package 2
- 28
- Warranty (in months)
- 18
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 3606482000308
- SAP 1200533569
- Code 82686502
Product Documentation
More from Schneider Electric
Schneider Electric
Schneider Electric switch disconnector Masterpact MTZ2 25 HF, 2500 A, 4 poles, fixed LV848081
Schneider Electric
Schneider Electric Circuit breaker, ComPacT NSX100HB2, 100KA/690VAC, 4 poles, MicroLogic 5.2E trip unit 40A C10W45E040
Schneider Electric
Schneider Electric Circuit breaker, ComPacT NSXm 160N, 50KA/415VAC, 3 poles, MicroLogic 4.1 trip unit 160A, EverLink lugs C12N34V160L
Schneider Electric
DIN-rail terminal 4mm² grey 2P
NSYTRV42
Schneider Electric
Schneider Electric Plastic window with hinged transparent cover. L78XW130XD25MM. NSYVA276MA
Schneider Electric
Schneider Electric NSYTRACE26 Linergy TR End Plate for Screw Terminal Blocks
Schneider Electric
Prefab. Connection Hor.plug-in NSX630/LGY 3P
LVS04461
Schneider Electric
Schneider Electric 19" fixed chassis 8U forPLA enclosure H500XW750MM NSYBRF8PLAG
