Schneider Electric Non-adjust delay unit - MN undervoltage release - 100/130 V AC/DC - spare part LV833684SP
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric LV833684SP Adjustable Time delay undervoltage coil MN 100/130VAC/DC Masterpact MTZ.
Technical Specifications
- Manufacturer part number (MPN)
- LV833684SP
- EAN / GTIN
- 3606481173393
- Sales unit
- pcs
- Package quantity
- 10 pcs
- Range
- MasterPact
- Device short name
- MN delay unit
- Product or component type
- Time delay auxiliary
- Device application
- Control
- Range compatibility
- Masterpact MasterPact MTZ1 circuit breaker; Masterpact MasterPact MTZ2 circuit breaker; Masterpact MasterPact MTZ3 circuit breaker
- Voltage release type
- Instantaneous
- Impulse duration
- 200 ms
- Time delay range
- 0.25 s
- [Uc] control circuit voltage
- 100...130 V AC 50/60 Hz; 100...130 V DC
- Threshold tripping voltage
- 0.35...0.7 Un open; 0.85 Un close
- Supply holding power
- 4.5 VA
- Supply inrush power
- 200 VA
- Response time
- 0.25 s
- Offer type
- Spare part
- Provided equipment
- 1 instruction sheet
- Number of Units in Package 1
- 1
- Number of Units in Package 2
- 10
- Country of origin
- FR
- Warranty (in months)
- 18
- Rated voltage
- 130 V
Standards & Compliance
- HS Code
- 8538.90
Cross References
- EAN 3606481173393
- SAP 1200050536
- Code 81878265
Product Documentation
