ATV630 IP00 160kW 400V DNV (ATV930C16N4428)
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric ATV930C16N4428 — Altivar variable-frequency drive. IGBT variable-frequency drive for AC motor speed control. Variable-frequency drive for pump & ventilation IP00 160KW 400V marine sertificat.
Technical Specifications
- Manufacturer part number (MPN)
- ATV930C16N4428
- EAN / GTIN
- 3606481714930
- HS code
- 8504.40
- Sales unit
- pcs
- Voltage
- 400 V
- IP rating
- IP00
- Power
- 160 kW
- Width
- 320 mm
- Height
- 852 mm
- Depth
- 393 mm
- Number of digital inputs
- 8
- Number of digital outputs
- 1
- Number of analogue inputs
- 3
- Number of analogue outputs
- 2
- Number of HW-interfaces RS-485
- 3
- Degree of protection (IP)
- IP00
- Mains frequency
- 50/60 Hz
- Type of converter
- U converter
- Number of phases output
- 3
- Number of phases input
- 3
- Max. output frequency
- 500 Hz
- Max. output at linear load at rated output voltage
- 160 kW
- Max. output at quadratic load at rated output voltage
- 160 kW
- Relative symmetric net voltage tolerance
- 10 %
- Relative symmetric net frequency tolerance
- 5 %
- Max. output voltage
- 480 V
- Nominal output current I2N
- 302 A
- Country of origin
- China
Standards & Compliance
- HS Code
- 8504.40
Cross References
- EAN 3606481714930
- SAP 1200722521
- Code 83865997
Product Documentation
More from Schneider Electric
Schneider Electric
Schneider Electric braking resistor - 100 ohms - 1.7 kW - IP20 VW3A7750
Schneider Electric
Wireless Receiver 4xPNP Outputs 24 VDC
ZBRRC
Schneider Electric
Screw set-Prisma P frameverk-set a 10
LVS08718
Schneider Electric
Schneider Electric braking resistor - 60 ohms - 0.5 kW - IP20 VW3A7741
Schneider Electric
Schneider Electric PratiKa socket - screw - angled - 32A - 3P + N + E - 380...415 V AC - wall PKF32W735
Schneider Electric
Schneider Electric Contactor, TeSys Deca, 3P(3NO), AC-3/3E, <=440V, 12A, 24V DC coil, snap-in terminals LC1D12ABD
Schneider Electric
Schneider Electric Illuminated push button, Harmony XB4, metal, white flush, 22mm, universal LED, plain lens, 1NO + 1NC, 24V AC DC, push in XB4BW31B55
Schneider Electric
Soft starter 11kW 25A 110-480V
ATS01N125FT
Technical guides
Catalogue entry last verified: 2026-09-29. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy ATV930C16N4428?
- ATV930C16N4428 can be ordered from cballast.com as a Schneider Electric catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Schneider Electric product?
- The manufacturer part number is ATV930C16N4428.
- What is the HS code for ATV930C16N4428?
- The customs tariff (HS) code for ATV930C16N4428 is 8504.40.
- Who manufactures ATV930C16N4428?
- ATV930C16N4428 is a Schneider Electric product in the Drives & Controllers range.
- Is a datasheet available for ATV930C16N4428?
- Yes — the ATV930C16N4428 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for ATV930C16N4428?
- The minimum order quantity is 1.
- Is ATV930C16N4428 available?
- Yes — ATV930C16N4428 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
