Schneider Electric Pack 22mm XB5R programble receiver AC/DC XB5RFA02
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric XB5RFA02 — Harmony XB4 22 mm command actuator. Metal or plastic 22 mm cutout push-button, selector or indicator. Wireless set with wireless push-button in plastic and receiver with 2 C/O outputs and 24-240V supply.
Technical Specifications
- Manufacturer part number (MPN)
- XB5RFA02
- EAN / GTIN
- 3606480334450
- Sales unit
- pcs
- Package quantity
- 16 pcs
- Range of product
- Harmony XB5R
- Product or component type
- Wireless and batteryless package
- Device short name
- XB5R
- Head material
- Plastic
- frequency
- 2405 MHz for transmitter; 2405 MHz for receiver
- emission class
- 5M00G7W
- Antenna type
- Omnidirectional
- Control type
- Wireless and batteryless push-button Ø 22 mm assembled on fixing collar
- Type of receiver
- Programmable receiver (2 relays)
- [Us] rated supply voltage
- 24...240 V AC/DC 50/60 Hz
- Kit composition
- 1 transmitter; 1 set of caps; 1 receiver; 1 fixing collars; 1 diameter: 22 mm; 1 push-button head diameter: 22 mm
- Status LED
- 1 LED green for power ON; 2 LEDs green for relay ON; 2 LEDs green for function mode; 1 LED green and yellow for reception signal
- Communication port protocol
- Zigbee conforming to IEEE 802.15.4
- Max power consumption in W
- 1 mW
- Number of channels
- 1
- Modulation Technique
- O-QPSK
- Bandwidth
- 5 MHz
- Product certifications
- UL; CCC; GOST; CSA; C-Tick
- Marking
- CE
- Standards
- CSA C22.2 No 14; IEC 60947-5-1; UL 508; IEC 60947-1
- Radio agreement
- SRRC; RSS; ARIB T66; FCC; ICASA; ANATEL
- Unit Type of Package 1
- PCE
- Number of Units in Package 1
- 1
- Package 1 Height
- 9.300 cm
- Package 1 Width
- 10.500 cm
- Package 1 Length
- 10.800 cm
- Package 1 Weight
- 207.000 g
- Unit Type of Package 2
- S03
- Number of Units in Package 2
- 16
- Package 2 Height
- 30.000 cm
- Package 2 Width
- 30.000 cm
- Package 2 Length
- 40.000 cm
- Package 2 Weight
- 3.850 kg
- Country of origin
- FR
- Warranty (in months)
- 18
- Hole diameter
- 22.5 mm
- Suitable for lighting
- No
- Number of command positions
- 1
- Spring-return
- Yes
- Type of button
- Flat
- Colour front ring
- Black
- Degree of protection (IP)
- IP65
- Material front ring
- Plastic
- With front ring
- Yes
- Transparent
- No
- Construction type lens
- Round
- Supply voltage lamp
- 24 V
- Switching function latching
- No
Standards & Compliance
- HS Code
- 8537.10
Cross References
- EAN 3606480334450
- SAP 1000263826
- Code 8249817
