3 avgan. RF busbar GV2 63A Snap-In
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric GV2G3RA — TeSys motor protection circuit breaker. Manual motor starter with thermal and magnetic protection. Linergy FT, busbar, connection hs, 63A, 3 branches, 45 mm pitch, for Snap-In GV2ME.
Technical Specifications
- Manufacturer part number (MPN)
- GV2G3RA
- EAN / GTIN
- 3606487864004
- Sales unit
- pcs
- Package quantity
- 4 pcs
- Rated current
- 63 A
- Range
- Linergy
- Product name
- FT
- Device short name
- GV2G
- Product or component type
- Comb busbar
- Accessory / separate part category
- Connection accessory
- Poles description
- 3P
- Range compatibility
- TeSys Deca; TeSys GV2
- Product compatibility
- GV2ME...A
- Fixing mode
- 35 mm symmetrical DIN rail: clipped
- Number of tap-offs
- 3
- Connections - terminals
- Push-in terminals: 1 cable(s) 1.5…16 mm² - solid; Push-in terminals: 1 cable(s) 1.5…25 mm² - flexible without cable end; Push-in terminals: 1 cable(s) 1.5…16 mm² - flexible with cable end; Push-in terminals: 1 cable(s) (16 AWG...10 AWG) - solid; Push-in terminals: 1 cable(s) (16 AWG...6 AWG) - stranded
- [Ith] conventional free air thermal current
- 63 A
- Product certifications
- CE; cULus
- [Ui] rated insulation voltage
- 690 V
- Connection pitch
- 45 mm
- Width
- 158 mm
- Product weight
- 0.54 kg
- Number of Units in Package 1
- 1
- Number of Units in Package 2
- 4
- Warranty (in months)
- 18
- Colour
- Black
- Insulated
- Yes
- Number of phases
- 3
- Rated permanent current Iu
- 63 A
- Number of poles
- 3
- Length
- 158 mm
- Width in number of modular spacings
- 45
- Suitable for devices with auxiliary switch
- No
- Suitable for devices with N-conductor
- No
- Suitable for number of devices
- 3
- Max. rated operation voltage Ue
- 690 V
- Module width
- 45 mm
- Can be cut to size
- No
- Country of origin
- China
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 3606487864004
- SAP 1200921980
- Code 84205840
Product Documentation
