Schneider Electric Modular liquid level control relay, 8 A, 1 CO, 380…415 V AC/DC RM22LG11MT

Schneider Electric Modular liquid level control relay, 8 A, 1 CO, 380…415 V AC/DC RM22LG11MT is listed under Control & Automation / Relays & Timers. HS code: 8536.49.

Manufacturer part number (MPN)

RM22LG11MT EAN / GTIN: 3606480792335 Sales unit: pcs Package quantity: 40 pcs Range of product: Harmony Control Relays Relay type: Level control relay Product or component type: Level control relay Relay name: RM22L Relay monitored parameters: Detection by resistive probes time delay: Without Switching capacity in VA: 2000 VA minimum switching current: 10 mA at 5 V DC Maximum switching current: 8 A AC Utilisation category: AC-15 conforming to IEC 60947-5-1; DC-13 conforming to IEC 60947-5-1; AC-1 conforming to IEC 60947-4-1; DC-1 conforming to IEC 60947-4-1 Contacts type and composition: 1 C/O Maximum switching voltage: 250 V AC [Un] rated nominal voltage: 380...415 V AC/DC 50/60 Hz, non self-powered Supply voltage limits: 323…456.5 V AC Output contacts: 2 C/O nominal output current: 8 A delay at power up: 0.6 s Maximum electrode voltage: 12 V AC Maximum electrode current: 1 mA Repeat accuracy: +/- 2 % for time delay Measurement error: < 1 % over the whole range with voltage variation; 0.05 %/°C with temperature variation Maximum cable distance between devices: 100 m between probe and delay Sensitivity scale: 5...100 kOhm St (Standard Sensitivity) Sensitivity adjustment: 5…100 % Maximum supply current for sensors: 1 mA Cable capacitance: 1 nF at HS (High Sensitivity) for probe cable; 2.2 nF at St (Standard Sensitivity) for probe cable; 4.7 nF at LS (Low Sensitivity) for probe cable Overvoltage category: III conforming to IEC 60664-1 Insulation: Between supply and measurement Connections - terminals: Screw terminals, 2 x 0.5...2 x 2.5 mm² (20 AWG...14 AWG) solid without cable end; Screw terminals, 2 x 0.2...2 x 1.5 mm² (24 AWG...16 AWG) flexible with cable end; Screw terminals, 1 x 0.5...1 x 3.3 mm² (20 AWG...12 AWG) solid without cable end; Screw terminals, 1 x 0.2...1 x 2.5 mm² (24 AWG...14 AWG) flexible with cable end Tightening torque: 0.6…1 N.m conforming to IEC 60947-1 Housing material: Polycarbonate Mounting support: 35 mm DIN rail conforming to IEC 60715 Mounting position: Any position Electrical durability: 100000 cycles Mechanical durability: 10000000 cycles Contacts material: Cadmium free Measurement range: 5...100 kOhm Safety reliability data: MTTFd = 125.5 years; B10d = 120000 Width: 22.5 mm Control type: With test button Product weight: 0.1 kg Immunity to microbreaks: 100 ms DC; 90 ms AC Electromagnetic compatibility: Immunity for residential, commercial and light-industrial environments conforming to IEC 61000-6-1; Immunity for industrial environments conforming to IEC 61000-6-2; Emission standard for residential, commercial and light-industrial environments conforming to IEC 61000-6-3; Emission standard for industrial environments conforming to IEC 61000-6-4; Electrostatic discharge - test level: 6 kV level 3 (contact discharge) conforming to IEC 61000-4-2; Electrostatic discharge - test level: 8 kV level 3 (air discharge) conforming to IEC 61000-4-2; Radiated radio-frequency electromagnetic field immunity test - test level: 10 V/m level 3 conforming to IEC 61000-4-3; Electrical fast transient/burst immunity test - test level: 4 kV level 4 (direct) conforming to IEC 61000-4-4; Electrical fast transient/burst immunity test - test level: 2 kV level 4 (capacitive coupling) conforming to IEC 61000-4-4; Surge immunity test - test level: 4 kV level 4 (common mode) conforming to IEC 61000-4-5; Surge immunity test - test level: 2 kV level 4 (differential mode) conforming to IEC 61000-4-5; Conducted and radiated emissions class B group 1 conforming to CISPR 11; Conducted and radiated emissions class B conforming to CISPR 22 Standards: IEC 60255-1 Product certifications: CSA; GL; RCM; UL; EAC; CE; CCC Ambient air temperature for storage: -40…70 °C Relative humidity: 93…97 % at 25…55 °C conforming to IEC 60068-2-30 Vibration resistance: 0.075 mm (f= 10…58.1 Hz) not in operation conforming to IEC 60068-2-6; 1 gn (f= 10…58.1 Hz) not in operation conforming to IEC 60068-2-6; 0.035 mm (f= 58.1…150 Hz) in operation conforming to IEC 60068-2-6; 0.5 gn (f= 58.1…150 Hz) in operation conforming to IEC 60068-2-6 Shock resistance: 15 gn (duration = 11 ms) for not in operation conforming to IEC 60068-2-27; 5 gn (duration = 11 ms) for in operation conforming to IEC 60068-2-27 IP degree of protection: IP20 (terminals) conforming to IEC 60529; IP40 (housing) conforming to IEC 60529; IP50 (front panel) conforming to IEC 60529 Pollution degree: 3 conforming to IEC 60664-1 Dielectric test voltage: 2.5 kV, 1 min AC 50 Hz conforming to IEC 60255-27 Unit Type of Package 1: PCE Number of Units in Package 1: 1 Package 1 Height: 2.6 cm Package 1 Width: 8.2 cm Package 1 Length: 9.5 cm Package 1 Weight: 107.0 g Unit Type of Package 2: S02 Number of Units in Package 2: 40 Package 2 Height: 15.0 cm Package 2 Width: 30.0 cm Package 2 Length: 40.0 cm Package 2 Weight: 4.711 kg Unit Type of Package 3: P06 Number of Units in Package 3: 640 Package 3 Height: 80.0 cm Package 3 Width: 80.0 cm Package 3 Length: 60.0 cm Package 3 Weight: 84.26 kg Country of origin: ID Warranty (in months): 18 Type of electric connection: Screw connection Rated control supply voltage AC 50 Hz: 380–415 V Rated control supply voltage AC 60 Hz: 380–415 V Voltage type for actuating: AC/DC With detachable clamps: No Number of inputs for electrodes: 3 Min. adjustable operate delay time: 0 s Min. adjustable off-delay time: 0 s Response value sensitivity adjustable: Yes Number of contacts as change-over contact: 1 Cascadable: No Height: 90 mm Depth: 73 mm

HS Code

8536.49

• EAN 3606480792335
• SAP 1000713422
• Code 8332061
