Schneider Electric screw socket equipped with LED and protection circuit, 110 V RSLZVA3

Schneider Electric RSLZVA3 Plinth 110VAC/DC.

Manufacturer part number (MPN)

RSLZVA3

EAN / GTIN

3606480078040

Sales unit

pcs

Package quantity

10 pcs

Voltage

110 V AC

Range of product

Harmony Electromechanical Relays

Device short name

RSLZ

Product or component type

Socket

Device presentation

Basic element

Product compatibility

Plug-in relay RSL with 1 C/O contact at 60 V DC; Plug-in relay RSL

Contacts type and composition

1 C/O

[Ith] conventional free air thermal current

6 A

Switching voltage

110 V AC/DC

Rated operational voltage limits

88...126.5 V

[Ue] rated operational voltage

< 300 V AC

Group of product

RSL_CON_110

Shape of pin

Flat

Contact terminal arrangement

Separate

Connections - terminals

Connector, 1 x 0.2...1 x 2.5 mm² (24 AWG...14 AWG) flexible with cable end; Connector, 1 x 0.2...1 x 2.5 mm² (24 AWG...14 AWG) solid without cable end

Compatibility code

RSLZ

Tightening torque

< 0.4 N.m for M2.5 screw(s)

Fixing mode

Plastic compression spring (35 mm symmetrical DIN rail)

[Uimp] rated impulse withstand voltage

3.6 kV

Overvoltage category

III

Pollution degree

3

Sale per indivisible quantity

10

CAD overall width

6.2 mm

CAD overall height

78.6 mm

CAD overall depth

95 mm

Product weight

0.023 kg

IP degree of protection

IP20 conforming to IEC 60529

Standards

IEC 61984; UL 508

Product certifications

GOST; CSA

Marking

CE

Ambient air temperature for storage

-40…85 °C

Ambient air temperature for operation

-40…55 °C

Number of Units in Package 1

1

Number of Units in Package 2

10

Number of Units in Package 3

300

Country of origin

CN

Warranty (in months)

18

Mounting method

DIN rail (top hat rail) 35 mm

Width

6.2 mm

Height

78.6 mm

Depth

95 mm

With detachable clamps

No

Function extension possible

No

Type of electric connection

Screw connection

Number of pins

5

HS Code

8536.90

• EAN 3606480078040
• SAP 1000090689
• Code 8925621
