Schneider Electric additionnal EMC filter S7 M2 - 1-Phase supply - 22 A VW3A31405

Schneider Electric VW3A31405 EMC filter ATV31, 1 X 230V, 22A.

Manufacturer part number (MPN)

VW3A31405

EAN / GTIN

3389110689471

Sales unit

pcs

Package quantity

11 pcs

Voltage

230 V

Range of product

Altivar

Product or component type

EMC input filter

Range compatibility

Altivar 312; Lexium 05; Altivar 312 Solar; Altivar 31C; Altivar Machine ATV320

Product compatibility

ATV312HU22M2; ATV31CU22M2; LXM05AD28F1; LXM05AD28M2; LXM05BD28F1; LXM05BD28M2; LXM05CD28M2; Variable speed drive ATV320...C motor: 2.2 kW, 200...240 V single phase; Variable speed drive ATV320...W/ATV320...WS motor: 2.2 kW, 200...240 V single phase

Product specific application

Radio interference input filter

[In] rated current

22 A

Thermal losses

7.5 W for ATV31CU22M2

Network number of phases

Single phase

maximum earth leakage current

80 mA 50 Hz

power supply voltage

200…240 V

Tolerance

10 %

Product weight

1.13 kg

IP degree of protection

IP20; IP41 (upper part)

Relative humidity

0…93 % conforming to IEC 68-2-3

Ambient air temperature for operation

-10…50 °C

Ambient air temperature for storage

-25…70 °C

Operating altitude

<= 1000 m without current derating; 1000...3000 m with current derating 1 % per 100 m

Vibration resistance

1 gn (f= 13…150 Hz) conforming to IEC 60068-2-6; 1.5 mm peak to peak (f= 3…13 Hz) conforming to IEC 60068-2-6

Shock resistance

15 gn for 11 ms conforming to IEC 60068-2-27

Standards

IEC 61800-3

Country of origin

TH

Warranty (in months)

18

Type of accessory/spare part

Filter

Accessory

Yes

Spare part

No

HS Code

8548.90

• EAN 3389110689471
• SAP 1000528406
• Code 8460132
