Mounting plate f/box 256X206
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric NSYPMD2520 Mounting plate f/box 256x206.
Technical Specifications
- Manufacturer part number (MPN)
- NSYPMD2520
- EAN / GTIN
- 3606480187964
- Sales unit
- pcs
- Dimensions
- 256×206 mm
- Range
- PanelSeT
- Accessory / separate part category
- Mounting accessory
- Product or component type
- Mounting plate
- Mounting location
- Bottom of enclosure
- Mounting plate description
- Plain
- Range compatibility
- PanelSeT
- Quantity per set
- Set of 1
- Fixing mode
- By screws - screw type M4
- Height
- Nominal: 256 mm
- Width
- Nominal: 206 mm
- Product weight
- 0.671 kg
- Number of Units in Package 1
- 1
- Country of origin
- ES
- Warranty (in months)
- 18
- Suitable for enclosure building width
- 206 mm
- Suitable for enclosure building height
- 256 mm
- Depth
- 88 mm
- Material
- Metal
- Colour
- Grey
- RAL-number
- 7035
Standards & Compliance
- HS Code
- 8538.10
Cross References
- EAN 3606480187964
- SAP 1200500835
- Code 82623874
Product Documentation
