Schneider Electric Cable entry membrane, PanelSeT, PanelSet, type FL21 with 7 entrances IP66 NSYAECPFLT7
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric NSYAECPFLT7 Spacial - Membrane Gland for cable gland - FL21 with 7 input IP66.
Technical Specifications
- Manufacturer part number (MPN)
- NSYAECPFLT7
- EAN / GTIN
- 3606480169038
- HS code
- 8544.42
- Sales unit
- pcs
- Range
- PanelSeT
- Product or component type
- Cable entry membrane
- Accessory / separate part category
- Cable management accessory
- Device application
- Multi-purpose
- Range compatibility
- PanelSeT S3D compact enclosure; PanelSeT CRN compact enclosure; PanelSeT SF SF suitable enclosure
- Device composition
- 1 membrane; 1 fixing elements
- Quantity per set
- Set of 1
- Mounting support
- Cable gland plate
- Material
- TPE (thermoplastic elastomer)
- Fixing mode
- By fixing element
- Total cable entry number
- 7
- Cable entry number
- 2 x 24…54 mm; 1 x 30…60 mm; 4 x 10…14 mm
- Height
- 40 mm
- Width
- External: 214 mm; Fixing center: 194 mm
- Depth
- Fixing center : 62 mm; External : 88 mm
- Colour
- Grey (RAL 7035)
- Product weight
- 0.29 kg
- IP degree of protection
- IP66
- Flame retardance
- V0 conforming to UL 94
- Ambient air temperature for operation
- -40…100 °C
- Environmental characteristic
- Oil resistant conforming to UL 157 FIMKO; UV resistant; Weatherproof; Fire resistance conforming to UL 94 V0
- Unit Type of Package 1
- PCE
- Number of Units in Package 1
- 1
- Package 1 Height
- 4.000 cm
- Package 1 Width
- 13.000 cm
- Package 1 Length
- 25.000 cm
- Package 1 Weight
- 291.000 g
- Unit Type of Package 2
- CAR
- Number of Units in Package 2
- 20
- Package 2 Height
- 20.000 cm
- Package 2 Width
- 40.000 cm
- Package 2 Length
- 30.000 cm
- Package 2 Weight
- 6.324 kg
- Unit Type of Package 3
- PAM
- Number of Units in Package 3
- 600
- Package 3 Height
- 85.000 cm
- Package 3 Width
- 100.000 cm
- Package 3 Length
- 120.000 cm
- Package 3 Weight
- 202.000 kg
- Country of origin
- FR
- Warranty (in months)
- 18
Standards & Compliance
- HS Code
- 8544.42
Cross References
- EAN 3606480169038
- SAP 1000488759
- Code 8803834
