Schneider Electric ClimaSys PTC heating resistance 20W, 12-24V NSYCR20WU1
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric NSYCR20WU1 HEATING ELEMENT 20 W 12-36V DC, ClimaSys.
Technical Specifications
- Manufacturer part number (MPN)
- NSYCR20WU1
- EAN / GTIN
- 3606480152122
- Sales unit
- pcs
- Voltage
- 12-36 V
- Power
- 20 W
- Range
- ClimaSys
- Product name
- ClimaSys CR
- Product or component type
- Resistance heater
- Power range
- 20 W
- Input voltage
- 12...24 V DC
- Electrical connection
- Cable 2 x 0.75 mm² length: 300 mm
- Operating position
- Vertical
- Ambient air temperature for operation
- -40…70 °C
- IP degree of protection
- IP20
- Product certifications
- UL; VDE
- Material
- Body: extruded aluminium
- Condition of use
- Air sealed enclosure; Heaters must be installed with a thermal controller; Electrical protection is needed
- fixing mode
- By clips
- Mounting support
- 35 mm DIN rail
- Number of Units in Package 1
- 1
- Country of origin
- CN
- Warranty (in months)
- 18
- Width
- 38 mm
- Height
- 98 mm
- Depth
- 75 mm
- Voltage type
- DC
- With room temperature controller
- No
- With fan
- No
- Degree of protection (IP)
- IP20
- Rated power
- 20 W
- Operating voltage DC
- 12–24 V
- Continuous heating power at 10 °C
- 20 W
Standards & Compliance
- HS Code
- 8516.29
Cross References
- EAN 3606480152122
- SAP 1000089013
- Code 8881587
Product Documentation
