Schneider Electric PrismaSeT P Form 4b Connection Cover, 4-6 Modules
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric LVS04954 is a Form 4b connection transfer cover for cable-field connections in PrismaSeT P enclosures. It accommodates four to six vertical 50 mm modules and is supplied in packs of three. The cover is finished in matt textured white RAL 9003 powder coating over an electrophoresis-treated base.
Technical Specifications
- Manufacturer part number (MPN)
- LVS04954
- EAN / GTIN
- 3606481880413
- Sales unit
- pcs
- Package quantity
- 3 pcs
- Range
- PrismaSeT
- Range of product
- PrismaSeT P
- Product or component type
- Cover
- Accessory / separate part category
- Insulation accessory
- Range compatibility
- PrismaSeT PrismaSeT P framework
- Cubicle partitioning form
- Form 4b
- installation description
- Cubicle
- Installed device
- connection transfer assembly
- Number of vertical modules [50 mm]
- 4; 5; 6
- Quantity per set
- Set of 1
- Width
- 330 mm
- Surface finish
- Matt; Textured
- Protective treatment
- Electrophoresis treatment and hot-polymerised polyester epoxy powder
- Colour
- White (RAL 9003)
- Product weight
- 2.7 kg
- Number of Units in Package 1
- 1
- Number of Units in Package 2
- 3
- Number of Units in Package 3
- 24
- Warranty (in months)
- 18
- Surface finishing
- Powder coating
- RAL-number
- 9003
- With cable entry
- No
- With lock
- No
- Construction type
- Individual part
- For internal separation form 2a
- No
- For internal separation form 2b
- No
- For internal separation form 3a
- No
- For internal separation form 3b
- No
- For internal separation form 4a
- No
- For internal separation form 4b
- No
- Country of origin
- Hungary
Standards & Compliance
- HS Code
- 7326.90
Cross References
- EAN 3606481880413
- SAP 1200547192
- Code 82879757
Product Documentation
