Shield clamp Horizontal 5/10mm_LGYE
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric LVS04664 — HORIZONTAL FIXED BUSBAR SUPPORT FOR LINERGY BS 5/10MM OR LINERGY LGYE.
Technical Specifications
- Manufacturer part number (MPN)
- LVS04664
- EAN / GTIN
- 3606481867148
- Sales unit
- pcs
- Package quantity
- 6 pcs
- Range
- Linergy
- Range of product
- Linergy
- Product or component type
- Busbar support
- Product name
- Linergy BS
- Range compatibility
- Linergy Linergy LGYE busbar; Linergy Linergy BS busbar; PrismaSeT PrismaSeT P enclosure
- Product compatibility
- Busbar support
- Cubicle-device connection
- Linergy BS horizontal busbar - fixed; Linergy LGYE horizontal busbar - fixed
- installation description
- Cubicle - width 650 + 150 mm
- Product weight
- 1.44 kg
- Quantity per set
- Set of 1
- Standards
- IEC 61439-1; IEC 61439-2
- Product certifications
- ASTA
- Unit Type of Package 1
- PCE
- Number of Units in Package 1
- 1
- Package 1 Height
- 6.500 cm
- Package 1 Width
- 5.800 cm
- Package 1 Length
- 34.400 cm
- Package 1 Weight
- 1.386 kg
- Unit Type of Package 2
- S02
- Number of Units in Package 2
- 6
- Package 2 Height
- 15.000 cm
- Package 2 Width
- 30.000 cm
- Package 2 Length
- 40.000 cm
- Package 2 Weight
- 8.658 kg
- Unit Type of Package 3
- P12
- Number of Units in Package 3
- 288
- Package 3 Height
- 99.000 cm
- Package 3 Width
- 80.000 cm
- Package 3 Length
- 120.000 cm
- Package 3 Weight
- 427.584 kg
- Country of origin
- FR
- Warranty (in months)
- 18
- Number of poles
- 4
- Busbar distance
- 75 mm
- Max. rated current
- 4000 A
Standards & Compliance
- HS Code
- 7326.90
Cross References
- EAN 3606481867148
- SAP 1200547017
- Code 82880236
Product Documentation
