C60B 40-3 Selective RCBO A9
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric A9N26263 Service-entrance MCB, Combined protection.
Technical Specifications
- Manufacturer part number (MPN)
- A9N26263
- EAN / GTIN
- 3606480784620
- Sales unit
- pcs
- Package quantity
- 48 pcs
- Built-in depth
- 44 mm
- Release characteristic
- B
- Number of poles (total)
- 3
- Number of protected poles
- 3
- Rated current
- 40 A
- Rated voltage
- 400 V
- Rated insulation voltage Ui
- 500 V
- Rated impulse withstand voltage Uimp
- 6 kV
- Frequency
- 50–60 Hz
- Current limiting class
- 3
- Concurrently switching neutral conductor
- No
- Overvoltage category
- 4
- Pollution degree
- 3
- Additional equipment possible
- Yes
- Width in number of modular spacings
- 3
- Degree of protection (IP)
- IP20
- Ambient temperature during operating
- -30–70 °C
- Connectable conductor cross section multi-wired
- 1–35 mm²
- Connectable conductor cross section solid-core
- 1–35 mm²
- Explosion-proof
- No
- Flush-mounted installation
- No
- Country of origin
- France
Standards & Compliance
- HS Code
- 8536.20
Cross References
- EAN 3606480784620
- SAP 1000679133
- Code 8576417
