NG125L/D 50-3 Modular Power Switch
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric 18854 NG125L/D 50-3 Modular power switch
Technical Specifications
- Manufacturer part number (MPN)
- 18854
- EAN / GTIN
- 3303430188544
- Sales unit
- pcs
- Package quantity
- 18 pcs
- Power loss
- 4.2 W
- Built-in depth
- 47 mm
- Release characteristic
- D
- Number of poles (total)
- 3
- Number of protected poles
- 3
- Rated current
- 50 A
- Rated voltage
- 415 V
- Rated insulation voltage Ui
- 690 V
- Rated impulse withstand voltage Uimp
- 8 kV
- Frequency
- 50–60 Hz
- Concurrently switching neutral conductor
- No
- Overvoltage category
- 4
- Pollution degree
- 3
- Additional equipment possible
- Yes
- Width in number of modular spacings
- 4.5
- Degree of protection (IP)
- IP20
- Ambient temperature during operating
- -30–70 °C
- Connectable conductor cross section multi-wired
- 1–35 mm²
- Connectable conductor cross section solid-core
- 1.5–50 mm²
- Explosion-proof
- No
- Flush-mounted installation
- No
- Country of origin
- France
Standards & Compliance
- HS Code
- 8536.20
Cross References
- EAN 3303430188544
- SAP 1000062443
- Code 8887961
Product Documentation
More from Schneider Electric
Schneider Electric
Schneider Electric 19" fixed chassis 12U PanelSeT NSYVDM12UF
Schneider Electric
Schneider Electric communication cable, 2 x RJ45 male connectors, 0.3 m length, set of 10 parts TRV00803
Schneider Electric
Cable 2XHE10, 10MTSXCD
TSXCDP1001
Schneider Electric
Schneider Electric NSYTRP24D Linergy TR Push-In Feed-Through 2-Level Terminal Block 2.5 mm² Grey 4-Position
Schneider Electric
Schneider Electric SURT007 APC Hardware Kit
Schneider Electric
Schneider Electric Connection Fixed MTZ1/NT 3P 1600A Prisma P LVS04489
Schneider Electric
Schneider Electric PanelSeT S3HF H400XW300XD200 EMC-immunity IP55 RAL7035 NSYS3HF4320P
Schneider Electric
Schneider Electric Control relay, TeSys Deca, 3NO+2NC, <=690V, 24V DC standard coil, snap-in terminals CAD32ABD
Technical guides
Catalogue entry last verified: 2026-09-30. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy 18854?
- 18854 can be ordered from cballast.com as a Schneider Electric catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Schneider Electric product?
- The manufacturer part number is 18854.
- What is the HS code for 18854?
- The customs tariff (HS) code for 18854 is 8536.20.
- Who manufactures 18854?
- 18854 is a Schneider Electric product in the Electrical Components range.
- Is a datasheet available for 18854?
- Yes — the 18854 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for 18854?
- The minimum order quantity is 1.
- Is 18854 available?
- Yes — 18854 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
