Schneider Electric KNB63SM48 TAPOFF UNIT 63A FOR MODULAR EQUIPMENT
Pricing
Request a quote
We reply within 24 hours
Overview
Schneider Electric KNB63SM48 TAPOFF UNIT 63A FOR MODULAR EQUIPMENT is listed under Electrical Components. Sales unit: pcs; Rated current: 63 A; Range of product: Canalis; Range compatibility: Canalis KN busbar trunking; Product or component type: Tap-off unit; busbar trunking compatibility: Canalis KN busbar trunkingplug-in.
Technical Specifications
- Manufacturer part number (MPN)
- KNB63SM48
- EAN / GTIN
- 3606480006319
- Sales unit
- pcs
- Rated current
- 63 A
- Range of product
- Canalis
- Range compatibility
- Canalis KN busbar trunking
- Product or component type
- Tap-off unit
- busbar trunking compatibility
- Canalis KN busbar trunkingplug-in
- [Ie] rated operational current
- 63 A
- Protection type
- Circuit breaker: miniature circuit breaker (MCB)
- Mounting mode
- Plug-in with fixed polarity
- Tap-off unit polarity
- 3L+N+PE
- Colour
- White (RAL 9001)
- Device application
- Low power distribution
- Provided equipment
- 8 circuit-breaker to be ordered separately; blanking plate
- [Ue] rated operational voltage
- 230...500 V depending on protective device
- [Uimp] rated impulse withstand voltage
- 4.6 kV
- [Ui] rated insulation voltage
- 400 V depending on protective device; 500 V depending on protective device
- Network frequency
- 50/60 Hz
- Electrical connection
- Tunnel terminal - ISO50 25 mm² flexible; Tunnel terminal - ISO50 25 mm² rigid
- door/cover opening side
- Right
- Tap-off unit disconnection mode
- By opening the door
- Standards
- IEC 61439-6; IEC 61439-1
- 18 mm pitches
- 8
- Width
- 344 mm
- Depth
- 106 mm
- depth (door open)
- 432.5 mm
- Height
- 165 mm
- Product weight
- 1.4 kg
- Earthing system
- TT; TN-S; IT
- IP degree of protection
- IP55 conforming to IEC 60529
- IK degree of protection
- IK08 conforming to IEC 62262
- Unit Type of Package 1
- PCE
- Number of Units in Package 1
- 1
- Package 1 Height
- 13.700 cm
- Package 1 Width
- 16.600 cm
- Package 1 Length
- 34.600 cm
- Package 1 Weight
- 1.566 kg
- Unit Type of Package 2
- P12
- Number of Units in Package 2
- 52
- Package 2 Height
- 60.000 cm
- Package 2 Width
- 80.000 cm
- Package 2 Length
- 120.000 cm
- Package 2 Weight
- 95.432 kg
- Country of origin
- IT
- Warranty (in months)
- 18
- RAL-number
- 9001
- With locking
- No
- Protection
- None
- Number of conductors (without earthing)
- 4
- Phase selection
- No
- Number of poles
- 4
- Length
- 344 mm
- Degree of protection (IP)
- IP55
- Branch off type
- Pipe in-lead
- Rated current AC 50 Hz
- 63 A
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 3606480006319
- SAP 1000470808
- Code 8797928
Product Documentation
More from Schneider Electric
Schneider Electric
DIN-rail terminal 6mm² PE 2P
NSYTRV62PE
Schneider Electric
Schneider Electric A9F94316 ACTI9 IC60L Miniature Circuit Breaker 3P 16 A, Curve C
Schneider Electric
Schneider Electric NSYS3X4420 PanelSet S3X stainless 304L, Scotch Brite® finish, H400XW400XD200 mm.
Schneider Electric
KB 65 .box 2X3-POLE screw terminal
IMT34068
Schneider Electric
Schneider Electric Residual current breaker with overcurrent protection (RCBO), ACTI9 IC60, 4P, 10A, C curve, 6000A/6KA, A-SI type, 30MA A9D77410
Schneider Electric
Schneider Electric Exxact Low-Voltage 4-Gang Push Button with LED
WDE002394
Schneider Electric
Measuring Box 6 Modules-PrismaSeT P
LVS03508
Schneider Electric
Schneider Electric Trip unit MicroLogic 5.3E, ComPacT NSX400/630, 4 poles, electronic basic protections, energy meter, 400A rating C4045E400
Technical guides
Catalogue entry last verified: 2026-09-30. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy KNB63SM48?
- KNB63SM48 can be ordered from cballast.com as a Schneider Electric catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Schneider Electric product?
- The manufacturer part number is KNB63SM48.
- What is the HS code for KNB63SM48?
- The customs tariff (HS) code for KNB63SM48 is 8536.90.
- Who manufactures KNB63SM48?
- KNB63SM48 is a Schneider Electric product in the Electrical Components range.
- Is a datasheet available for KNB63SM48?
- Yes — the KNB63SM48 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for KNB63SM48?
- The minimum order quantity is 1.
- Is KNB63SM48 available?
- Yes — KNB63SM48 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
