refrigeration unit Blue e+ Outdoor 1500 W

Rittal 3185330 Manufacturer description: SK Blue e+ cooling unit, wall-mounted, outdoor, 5118 BTU/h 110 –; 240 V, 1~, 380 – 480 V, 3~, 50 – 60 Hz, aluminum, WHD: 400 x 950 x; 310 mm. Blue e+ cooling unit, wall-mounted, outdoor, 1.6 kW, 110 – 240 V, 1~, 380 – 480 V, 3~, 50 – 60 Hz.

Manufacturer part number (MPN)

3185330 EAN / GTIN: 4028177958562 Sales unit: pcs Model designation: SK 3185.330 Product type: Wall-mounted air conditioner Blue e Version: wall-mounted; Outdoor material: Aluminum AlMg3 Surface finish: Powder-coated; UV-resistant pure polyester Color: RAL 7035 Supply includes: Condenser with hydrophobic RiNano coating; Integral electric condensate evaporation; Wired ready for connection (plug-in terminal strip); Mounting frame for universal attachment to outdoor enclosures for surface mounting, partially internal installation and fully internal installation; Assembly components Options: For remote monitoring and networking of cooling units and chillers, use the Blue e+ Generation IoT Interface, item number 3124.300.; Increase machine availability and process safety by remote monitoring of device data, condition, and system messages. Rated operating voltage: 110 V - 240 V, 1~, 50 Hz/60 Hz; 380 V - 480 V, 3~, 50 Hz/60 Hz Note on Model No.: Tolerance: 110 V -10% (99 V) and 240 V +10% (264 V) / 380 V -10% (342 V) and 480 V +6% (509 V) Rated output: 0.7 kW Rated power Pel: Rated power L35 L35/50 Hz: 0.57 kW; Rated power L35 L35/60 Hz: 0.57 kW; Rated power L35 L50/50 Hz: 0.64 kW; Rated power L35 L50/60 Hz: 0.64 kW Temperature control: e+ controller (factory setting +35 °C) Dimensions: Width: 415 mm; Height: 990 mm; Depth: 280 mm Installation type: Universal installation (surface-mounting, partial internal installation and full internal installation) Protection category NEMA: with mounting frame: UL Type 12/3R/4 without mounting frame: UL Type 12/3R Air throughput (unimpeded air flow): External circuit: 895 m³/h; Internal circuit: 700 m³/h; External circuit: 526.8 cfm; Internal circuit: 412 cfm Refrigerant/cooling medium: Refrigerant: R-513A; Quantity: 0.76 kg; Global Warming Potential (GWP): 631; CO2 equivalent (CO2e): 0.48 t; Refrigerant: R-513A; Quantity: 1.7 lb. Energy efficiency ratio (EER) 50/60: Refrigeration factor L35 L35 (EER) 50 Hz: 2.61 Hz L35 L35: Refrigeration factor L35 L35 (EER) 60 Hz: 2.61 Suitable for Model No.: 9782.818 Setting range: 20 °C...50 °C; 68 °F...122 °F Operating temperature range: -30 °C...60 °C; -22 °F...140 °F Operating temperature range of refrigerant circuit (active): 3 °C...60 °C Operating temperature range of heat pipe: -30 °C...45 °C Storage temperature range: -40 °C...70 °C; -40 °F...158 °F Permissible operating pressure (p. max.): 2.4 Noise pressure level: 67 dB(A) Packaging unit: 1 pc(s). Net weight: 36 kg Gross weight: 48 kg PCF/VE (cradle-to-gate): 674.84 Customs tariff number: 84158200 ETIM 9: EC000855 ETIM 8: EC000855 ECLASS 8.0: 27180704 Width: 415 mm Height: 990 mm Depth: 280 mm Voltage type: AC With heating function: No With temperature control: Yes Function master/slave: Yes Total cooling capacity according to EN 14511 at 35/35 °C: 1500 W Speed-regulated: Yes Cooling air flow rate: 0–895 m³/h Country of origin: Italy

HS Code

8415.82

• EAN 4028177958562
• SAP 1200596622
• Code 82971994
