MTS 1-Phase Safety Transformer P: 160VA In: 230/400VAC Out: 24VAC
Pricing
Request a quote
We reply within 24 hours
Product Description
Murrelektronik 86343 — MTS 1-PHASE SAFETY TRANSFORMER P: 160VA IN: 230/400VAC OUT: 24VAC. Single-phase safety transformer 160 VA Isolation class T 40/B Other voltages on request.
Technical Specifications
- Manufacturer part number (MPN)
- 86343
- Model designation
- MTS 0160-230-400/24
- EAN / GTIN
- 4048879078528
- HS code
- 8504.31
- EU customs tariff number
- 85043180
- US customs tariff number
- 8504314065
- Weight
- 3.074 kg
- Country of origin
- CZ
- Sales unit
- pcs
- Electrical data | Supply - Protective measure
- SELV
- Electrical data | Supply - Power frequency
- 50 ... 60 Hz
- Electrical data | Input - Nominal input voltage AC
- 230 V … 400 V
- Electrical data | Input - Nominal current AC
- 0.82 A @ 230 V,0.47 A @ 400 V
- Input - Inrush current at input voltage 1
- 6.1 A
- Input - Inrush current at input voltage 2
- 3.5 A
- Input - Short-circuit current at input voltage 1
- 9.5 A
- Input - Short-circuit current at input voltage 2
- 5.5 A
- Electrical data | Output - Output voltage adjustable
- No
- Electrical data | Output - Output voltage AC
- 24 V
- Electrical data | Output - Power rating AC max.
- 160 VA
- Electrical - Insulation test voltage input - output
- 4 kV
- Mechanical data | Mounting data - Height
- 101 mm
- Mechanical data | Mounting data - Width
- 96 mm
- Mechanical data | Mounting data - Depth
- 106 mm
- Mechanical data | Mounting data - Mounting method
- geschnappt
- Mounting data - Suitable for mounting type
- Mounting rail TH35, Long-hole mounting, (EN 60715)
- Mechanical data | Mounting data - Mounting dimension a
- 86.5 mm
- Mechanical data | Mounting data - Mounting dimension b
- 84 mm
- Mechanical data | Mounting data - Mounting dimension c
- 4.8 mm
- Mechanical data | Mounting data - Diameter bore
- 4.8 mm
- Mechanical data | Mounting data - Length bore
- 8.4 mm
- Climatic - Operating temperature min.
- -20 °C
- Climatic - Operating temperature max.
- 40 °C
- Climatic - Ambient temperature (storage, transport)
- -40 °C … 80 °C
- Conformity - Product standard
- EN IEC 61558-2-4, EN IEC 61558-2-6, IEC 62041 category 0
- Connection types - Connection type 1
- Input
- Connection types - Connection type 2
- Output
- Connection type 1 - Family construction form
- terminal
- Connection type 1 - No. of poles
- 3
- Connection type 1 - Gender
- female
- Connection type 1 - Connection
- Screw terminals SK
- Connection type 1 - PIN 2
- 230 V
- Connection type 1 - PIN 3
- 400 V
- Connection type 2 - Family construction form
- terminal
- Connection type 2 - No. of poles
- 2
- Connection type 2 - Gender
- female
- Connection type 2 - Connection
- Screw terminals SK
- Connection type 2 - PIN 2
- 24 V DC
- Connection type 3 - Family construction form
- terminal
- Connection type 3 - No. of poles
- 1
- Connection type 3 - Gender
- female
- Connection type 3 - Color contact carrier
- metallic
- Connection type 3 - Connection
- Screw terminals SK
- Connection type 3 - PIN 1
- PE
- ETIM-5.0
- EC002486
- ETIM-6.0
- EC002486
- ETIM-7.0
- EC002486
- ETIM-8.0
- EC002486
- ETIM-9.0
- EC002486
- ETIM-10.0
- EC002486
- Packaging unit
- 1
- ECLASS 14.0
- 27031302
Standards & Compliance
- HS Code
- 8504.31
Cross References
- EAN 4048879078528
- SAP 1000455128
- Code 8560937
Product Documentation
More from Murrelektronik
Murrelektronik
MET 1-Phase Control AND Isolation Transformer P: 500VA In: 400VAC+/- 5% Out: 230VAC
86021
Murrelektronik
MST 1-Phase Control AND Isolation Transformer P: 1000VA In: 230/400VAC Out: 230VAC
86311
Murrelektronik
MST 1-Phase Control AND Isolation Transformer P: 400VA In: 230/400VAC Out: 230VAC
86307
Murrelektronik
MTS 1-Phase Safety Transformer P: 63VA In: 230/400VAC Out: 24VAC
86341
Murrelektronik
MTS 1-Phase Safety Transformer P: 100VA In: 230/400VAC Out: 24VAC
86342
Murrelektronik
M8 female 90° A-cod. with cable LED F&B PVC 3X0.25 gy UL/CSA 10M
7014-08121-2101000
Murrelektronik
RJ45 male 0° / RJ45 male 0° shielded PUR 1X4XAWG22 shielded bu UL/CSA+drag ch. 1M
7000-74301-6770100
Murrelektronik
RJ45 male 0° / RJ45 male 0° shielded FRNC/LS0H 4X2XAWG27 shielded gr UL 1M (7000-74711-7780100)
Catalogue entry last verified: 2026-09-29. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy 86343?
- 86343 can be ordered from cballast.com as a Murrelektronik catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Murrelektronik product?
- The manufacturer part number is 86343.
- What is the HS code for 86343?
- The customs tariff (HS) code for 86343 is 8504.31.
- Who manufactures 86343?
- 86343 is a Murrelektronik product in the Electrical Components range.
- Is a datasheet available for 86343?
- Yes — the 86343 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for 86343?
- The minimum order quantity is 1.
- Is 86343 available?
- Yes — 86343 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
