MST 1-Phase Control AND Isolation Transformer P: 1000VA In: 230/400VAC Out: 230VAC
Pricing
Request a quote
We reply within 24 hours
Product Description
Murrelektronik 86311 — MST 1-PHASE CONTROL AND ISOLATION TRANSFORMER P: 1000VA IN: 230/400VAC OUT: 230VAC. Single-phase - Control and Isolation Transformers 1000 VA Isolation class T 40/B Other voltages on request.
Technical Specifications
- Manufacturer part number (MPN)
- 86311
- Model designation
- MST 1000-230-400/230
- EAN / GTIN
- 4048879078627
- HS code
- 8504.31
- EU customs tariff number
- 85043180
- US customs tariff number
- 8504314065
- Weight
- 12.450 kg
- Country of origin
- CZ
- Sales unit
- pcs
- Electrical data | Supply - Power frequency
- 50 ... 60 Hz
- Electrical data | Input - Nominal input voltage AC
- 230 V … 400 V
- Electrical data | Input - Nominal current AC
- 4.73 A @ 230 V,2.72 A @ 400 V
- Input - Inrush current at input voltage 1
- 66 A
- Input - Inrush current at input voltage 2
- 38 A
- Input - Short-circuit current at input voltage 1
- 148 A
- Input - Short-circuit current at input voltage 2
- 85 A
- Electrical data | Output - Output voltage adjustable
- No
- Electrical data | Output - Output voltage AC
- 230 V
- Electrical data | Output - Power rating AC max.
- 1.000 VA
- Electrical - Insulation test voltage input - output
- 4 kV
- Mechanical data | Mounting data - Height
- 128 mm
- Mechanical data | Mounting data - Width
- 174 mm
- Mechanical data | Mounting data - Depth
- 160 mm
- Mounting data - Suitable for mounting type
- Keyhole mounting
- Mechanical data | Mounting data - Mounting dimension a
- 102 mm
- Mechanical data | Mounting data - Mounting dimension b
- 135 mm
- Mechanical data | Mounting data - Mounting dimension c
- 7 mm
- Mechanical data | Mounting data - Diameter bore
- 7 mm
- Mechanical data | Mounting data - Length bore
- 11 mm
- Climatic - Operating temperature min.
- -20 °C
- Climatic - Operating temperature max.
- 40 °C
- Climatic - Ambient temperature (storage, transport)
- -40 °C … 80 °C
- Conformity - Product standard
- EN IEC 61558-1, EN IEC 61558-2-4, IEC 62041 category 0
- ETIM-5.0
- EC002486
- ETIM-6.0
- EC002486
- ETIM-7.0
- EC002486
- ETIM-8.0
- EC002486
- ETIM-9.0
- EC002486
- ETIM-10.0
- EC002486
- Packaging unit
- 1
- ECLASS 14.0
- 27031302
Standards & Compliance
- HS Code
- 8504.31
Cross References
- EAN 4048879078627
- SAP 1000455133
- Code 81089106
Product Documentation
