MST 1-Phase Control AND Isolation Transformer P: 800VA In: 230/400VAC Out: 230VAC
Pricing
Request a quote
We reply within 24 hours
Product Description
Murrelektronik 86310 — MST 1-PHASE CONTROL AND ISOLATION TRANSFORMER P: 800VA IN: 230/400VAC OUT: 230VAC. Single-phase - Control and Isolation Transformers 800 VA Isolation class T 40/B Other voltages on request.
Technical Specifications
- Manufacturer part number (MPN)
- 86310
- Model designation
- MST 0800-230-400/230
- EAN / GTIN
- 4048879078634
- HS code
- 8504.31
- EU customs tariff number
- 85043180
- US customs tariff number
- 8504314065
- Weight
- 10.100 kg
- Country of origin
- CZ
- Sales unit
- pcs
- Electrical data | Supply - Power frequency
- 50 ... 60 Hz
- Electrical data | Input - Input voltage AC
- 110 V
- Electrical data | Input - Nominal input voltage AC
- 230 V
- Electrical data | Input - Input voltage 3 AC
- 400 V
- Electrical data | Input - Nominal current AC
- 3.5 A @ 230 V
- Input - Input current at input voltage 3 AC
- 2 A
- Input - Inrush current at input voltage 2
- 50 A
- Input - Inrush current at input voltage 3
- 29 A
- Electrical data | Input - Short-circuit current
- 219 A
- Electrical data | Output - Output voltage adjustable
- No
- Electrical data | Output - Output voltage AC
- 230 V
- Electrical data | Output - Power rating AC max.
- 800 VA
- Electrical - Insulation test voltage input - output
- 4 kV
- Mechanical data | Mounting data - Height
- 129.4 mm
- Mechanical data | Mounting data - Width
- 150 mm
- Mechanical data | Mounting data - Depth
- 144.6 mm
- Mounting data - Suitable for mounting type
- Keyhole mounting
- Mechanical data | Mounting data - Mounting dimension a
- 107.5 mm
- Mechanical data | Mounting data - Mounting dimension b
- 122 mm
- Mechanical data | Mounting data - Mounting dimension c
- 7 mm
- Mechanical data | Mounting data - Diameter bore
- 7 mm
- Mechanical data | Mounting data - Length bore
- 11 mm
- Climatic - Operating temperature min.
- -20 °C
- Climatic - Operating temperature max.
- 40 °C
- Climatic - Ambient temperature (storage, transport)
- -40 °C … 80 °C
- Conformity - Product standard
- EN IEC 61558-1, EN IEC 61558-2-4, IEC 62041 category 0
- Connection types - Connection type 1
- Input
- Connection types - Connection type 2
- Output
- Connection type 1 - Family construction form
- terminal
- Connection type 1 - No. of poles
- 3
- Connection type 1 - Gender
- female
- Connection type 1 - Connection
- Screw terminals SK
- Connection type 1 - PIN 2
- 230 V
- Connection type 1 - PIN 3
- 400 V
- Connection type 2 - Family construction form
- terminal
- Connection type 2 - No. of poles
- 2
- Connection type 2 - Gender
- female
- Connection type 2 - Connection
- Screw terminals SK
- Connection type 2 - PIN 2
- 230 V
- Connection type 3 - Family construction form
- terminal
- Connection type 3 - No. of poles
- 1
- Connection type 3 - Gender
- female
- Connection type 3 - Color contact carrier
- metallic
- Connection type 3 - Connection
- Screw terminals SK
- Connection type 3 - PIN 1
- PE
- ETIM-5.0
- EC002486
- ETIM-6.0
- EC002486
- ETIM-7.0
- EC002486
- ETIM-8.0
- EC002486
- ETIM-9.0
- EC002486
- ETIM-10.0
- EC002486
- Packaging unit
- 1
- ECLASS 14.0
- 27031302
Standards & Compliance
- HS Code
- 8504.31
Cross References
- EAN 4048879078634
- SAP 1000268765
- Code 81152605
