MST 1-Phase Control AND Isolation Transformer P: 2000VA In: 208...550VAC Out: 2X115VAC

Murrelektronik 86153 — MST 1-PHASE CONTROL AND ISOLATION TRANSFORMER P: 2000VA IN: 208.550VAC OUT: 2x115VAC. Single-phase - Control and Isolation Transformers 2000 VA Isolation class T 40/B Other voltages on request.

Manufacturer part number (MPN)

86153

Model designation

MST 2000-208...550/2x115

EAN / GTIN

4048879078702

HS code

8504.32

EU customs tariff number

85043200

US customs tariff number

8504320000

Weight

27.500 kg

Country of origin

CZ

Sales unit

pcs

Electrical data | Supply - Power frequency

50 ... 60 Hz

Electrical data | Input - Input voltage AC

420, 208, 525, 550, 230, 380, 400, 440, 460, 480, 500

Electrical data | Input - Nominal input voltage AC

208 V … 550 V

Electrical data | Input - Nominal current AC

10.2 A @ 208 V,3.86 A @ 550 V

Input - Inrush current at input voltage 1

179 A

Input - Inrush current at input voltage 2

68 A

Input - Short-circuit current at input voltage 1

473 A

Input - Short-circuit current at input voltage 2

180 A

Electrical data | Output - Output voltage adjustable

Yes

Electrical data | Output - Output voltage

1 × 230 / 1 × 115 / 2 × 115 V AC

Electrical data | Output - Output voltage AC 1

230 V

Electrical data | Output - Output voltage AC 2

115 V

Electrical data | Output - Power rating AC max.

2.000 VA

Electrical - Insulation test voltage input - output

4 kV

Mechanical data | Mounting data - Height

185 mm

Mechanical data | Mounting data - Width

192 mm

Mechanical data | Mounting data - Depth

185 mm

Mounting data - Suitable for mounting type

Keyhole mounting

Mechanical data | Mounting data - Mounting dimension a

155 mm

Mechanical data | Mounting data - Mounting dimension b

150 mm

Mechanical data | Mounting data - Mounting dimension c

10 mm

Mechanical data | Mounting data - Diameter bore

10 mm

Mechanical data | Mounting data - Length bore

18 mm

Climatic - Operating temperature min.

-20 °C

Climatic - Operating temperature max.

40 °C

Climatic - Ambient temperature (storage, transport)

-40 °C … 80 °C

Conformity - Product standard

EN IEC 61558-1, EN IEC 61558-2-4, IEC 62041 category 0

Connection types - Connection type 1

Input

Connection types - Connection type 2

Input

Connection types - Connection type 3

Output

Connection types - Connection type 4

Output

Connection type 1 - Family construction form

terminal

Connection type 1 - No. of poles

8

Connection type 1 - Gender

female

Connection type 1 - Connection

Screw terminals SK

Connection type 1 - PIN 1

1

Connection type 1 - PIN 2

2

Connection type 1 - PIN 3

3

Connection type 1 - PIN 4

4

Connection type 1 - PIN 5

5

Connection type 1 - PIN 6

6

Connection type 1 - PIN 7

7

Connection type 1 - PIN 8

8

Connection type 2 - Family construction form

terminal

Connection type 2 - No. of poles

8

Connection type 2 - Gender

female

Connection type 2 - Connection

Plug-in terminals RK

Connection type 2 - PIN 1

1

Connection type 2 - PIN 2

2

Connection type 2 - PIN 3

3

Connection type 2 - PIN 4

4

Connection type 2 - PIN 5

5

Connection type 2 - PIN 6

6

Connection type 2 - PIN 7

7

Connection type 2 - PIN 8

8

Connection type 3 - Family construction form

terminal

Connection type 3 - No. of poles

4

Connection type 3 - Gender

female

Connection type 3 - Connection

Screw terminals SK

Connection type 3 - PIN 1

9

Connection type 3 - PIN 2

10

Connection type 3 - PIN 3

11

Connection type 3 - PIN 4

12

Connection type 4 - Family construction form

terminal

Connection type 4 - No. of poles

4

Connection type 4 - Gender

female

Connection type 4 - Connection

Plug-in terminals RK

Connection type 4 - PIN 1

9

Connection type 4 - PIN 2

10

Connection type 4 - PIN 3

11

Connection type 4 - PIN 4

12

Connection type 5 - Family construction form

terminal

Connection type 5 - No. of poles

1

Connection type 5 - Gender

female

Connection type 5 - Color contact carrier

metallic

Connection type 5 - Connection

Screw terminals SK

Connection type 5 - PIN 1

PE

ETIM-5.0

EC002486

ETIM-6.0

EC002486

ETIM-7.0

EC002486

ETIM-8.0

EC002486

ETIM-9.0

EC002486

ETIM-10.0

EC002486

Packaging unit

1

ECLASS 14.0

27031302

HS Code

8504.32

• EAN 4048879078702
• SAP 1000455140
• Code 8791103
