Graco XM70 Skid System, Non-Hazardous, with Water Jacketed Hose and 25 Gallon Heated Hoppers, 480V
Pricing
Request a quote
We reply within 24 hours
Product Description
Graco XM7H2W XM70 Skid System, Non-Hazardous, With Water Jacketed Hose and 25 Gallon Heated Hoppers, 480V, part number XM7H2W. Plural Component Sprayer (XM70). Mix ratio 1:1-10:1. Maximum working pressure 6300 psi (435 bar); maximum fluid flow 3 gpm (11.4 lpm). Includes: Water Jacketed Hose, 25 Gallon Heated Hoppers, Remote Carriage, Viscon HF, 30:1 Merkur Pump, XTR+ Gun, 25 ft Xtreme Duty Airless Hose, 10 ft Xtreme Duty Whip hose, Junction Box. All values read from the Graco product page (XM7H2W on graco.com).
Technical Specifications
- Brand
- Graco Model: XM70 Part number: XM7H2W Maximum working pressure: 6300 psi (435 bar) Maximum flow rate: 3 gpm (11.4 lpm) Type: Plural Component Sprayer minimum mix ratio: 1:1 Maximum mix ratio: 10:1 Mix accuracy: 5% Tank capacity: 25 Power source: Wall Air inlet size: 3/4 in. Female NPT Sound pressure level: 84.8 at 70psi (0.48 MPa, 4.8 bar) dB(A) Includes: Water Jacketed Hose, 25 Gallon Heated Hoppers, Remote Carriage, Viscon HF, 30:1 Merkur Pump, XTR+ Gun, 25 ft Xtreme Duty Airless Hose, 10 ft Xtreme Duty Whip hose, Junction Box Voltage: 480 V
Standards & Compliance
- Pressure Rating
- 6300 psi (435 bar) max working
- HS Code
- 8424.20
Compatibility & Fitment
XM is Graco's plural-component (two-component) proportioning spray line for protective coatings and materials. The 1:1-10:1 mix ratio range and the wetted-material set determine which coatings this configuration handles. This configuration includes: Water Jacketed Hose, 25 Gallon Heated Hoppers, Remote Carriage, Viscon HF, 30:1 Merkur Pump, XTR+ Gun, 25 ft Xtreme Duty Airless Hose, 10 ft Xtreme Duty Whip hose, Junction Box. Confirm the electrical supply (phase/voltage), hopper/feed configuration and gun/tip suit the coating before ordering.
