Fluke BK120 SmartTrace™ Breaker Finder and 107 Pocket Digital Multimeter

Enhance your toolset with the BK120 breaker finder and 107 digital multimeter (DMM). The perfect pair for circuit identification and electrical measurements.

Manufacturer part number (MPN)

5587530

Brand

Fluke

Category

Tools

BK120 Transmitter

BK120 Receiver

Breaker finder indication —

Visual and audio

NCV detection —

90 V AC to 240 V AC, 50/60 Hz Dual sensitivity Visual and audio indications

Flashlight —

✓

Auto power off —

✓

Low battery indication —

✓

Power supply Line powered

2 AAA

AC voltage (40 Hz to 500 Hz)1 Range

Resolution

6.000 V 60.00 V 600.0 V 0.001 V 0.01 V 0.1 V

1.0 % + 3

DC voltage 6.000 V 60.00 V 600.0 V

0.001 V 0.01 V 0.1 V

Exchange millivolts 600.0 mV

0.1 mV

Diode test2 2.000 V

0.001 V

400.0 Ω 4.000 kΩ 40.00 kΩ 400.0 kΩ 4.000 MΩ 40.00 MΩ

0.1 Ω 0.001 kΩ 0.01 kΩ 0.1 kΩ 0.001 MΩ 0.01 MΩ

50.00 nF 500.0 nF 5.000 μF 50.00 μF 500.0 μF 1000 μF

0.01 nF 0.1 nF 0.001 μF 0.01 μF 0.1 μF 1 μF

50.00 Hz 500.0 Hz 5.000 kHz 50.00 kHz 100.0 kHz

0.01 Hz 0.1 Hz 0.001 kHz 0.01 kHz 0.1 kHz

Duty cycle4 1 % to 99 %

0.10 %

AC current (40 Hz - 200 Hz) 4.000 A 10.00 A

0.001 A 0.01 A

DC 4.000 A 10.00 A

0.001 A 0.01 A

Features Overload protection

Input impedance (nominal value)

AC voltage 600 V 1

>10 MΩ 2

Exchange millivolts 600 mV

>1M, <100 pF

DC voltage 600 V 1

>10 MΩ <100 pF

The highest voltage applied to any terminal and ground

600 V

Display (LCD)

6000 counts, updated three times per second

Type of battery

Two AAA batteries (NEDA 24A, IEC LR03)

Battery life

At least 200 hours

Operating temperature

0 °C to 40 °C

Storage temperature

-30 °C to 60 °C

Working humidity

No condensation below 10 °C ≤ 90 % at 10 °C to 30 °C; ≤ 75 % at 30 °C to 40 °C

Working humidity, 40 MΩ range

≤ 80 % at 10 °C to 30 °C; ≤ 70 % at 30 °C to 40 °C

Working elevation

2000 m

Storage altitude

12,000 m

Temperature coefficient

0.1 X (specified accuracy) / °C (28 °C)

Current input fuse protection

11A, 1000V fast-melting type, must use Fluke designated parts

Volume (height x width x length)

142 mm x 69 mm x 28 mm

Weight

200 g

Protection level

IEC 60529: IP 40

Safety

IEC 61010-1: 600 V CAT III, pollution degree 2

Electromagnetic environment

IEC 61326-1: Portable

Electromagnetic compatibility

Applicable only in Korea. Class A equipment (industrial broadcasting and communication equipment)1

HS Code

9030.33
