Festo
Festo VUWG-L10-T32C-A-M7 Pneumatic valve
Part number573821EAN / GTIN4052568221102HS code8481.20
Pneumatics
Pneumatic Valves
MOQ:1
Pricing
Request a quote
We reply within 24 hours
Product Description
Festo VUWG-L10-T32C-A-M7 — Pneumatic valve, universal directional control valves. valve function 2x3/2 closed monostable; operating pressure 1.5. 10 bar.
Technical Specifications
- Manufacturer part number (MPN)
- 573821
- Type code
- VUWG-L10-T32C-A-M7
- EAN / GTIN
- 4052568221102
- Product category
- Universal directional control valves
- Valve function
- 2x3/2 closed monostable
- Type of actuation
- Pneumatic
- Valve size
- 10 mm
- Standard nominal flow rate (standardised to DIN 1343)
- 190 l/min
- pneumatic working port
- M7
- Operating pressure
- 1.5 ... 10 bar
- Design
- Piston gate valve
- Type of reset
- Pneumatic spring
- Grid dimension
- 10.5 mm
- Exhaust-air function
- Can be throttled
- Sealing principle
- Soft
- Mounting position
- Any
- Manual override
- None
- Type of piloting
- Direct
- Flow direction
- Reversible with restrictions
- Symbol
- 00992930
- lap
- Overlap
- Pilot pressure
- 1.5 ... 10 bar
- Suitability for vacuum
- No
- Switching time off
- 9 ms
- Switching time on
- 4 ms
- Operating medium
- Compressed air to ISO 8573-1:2010 [7:4:4]
- Corrosion resistance class CRC
- 2 - Moderate corrosion stress
- LABS (PWIS) conformity
- VDMA24364-B1/B2-L
- Cleanroom suitability, measured according to ISO 14644-14
- Class 5 according to ISO 14644-1
- Media temperature
- -5 ... 50 °C
- Pilot medium
- Compressed air to ISO 8573-1:2010 [7:4:4]
- Ambient temperature
- -5 ... 60 °C
- Product weight
- 48 g
- Type of mounting
- On PR rail, with through-hole
- Pilot air port 12
- M5
- Pilot air port 14
- M5
- Pneumatic connection, port 1
- M7
- Pneumatic connection, port 2
- M7
- Pneumatic connection, port 3
- M7
- Pneumatic connection, port 4
- M7
- Pneumatic connection, port 5
- M7
- Material seals
- HNBR, NBR
- Material housing
- anodised
- Product type
- Pneumatic Valves Air-Controlled
- Product group
- Pneumatics
- Thread
- M7"
- Activation
- Air
- Return
- Spring
- Carbon footprint (EPD)
- 0.9928 kg CO2e per pcs
- Country of origin
- Germany
- Customs tariff code (EU CN)
- 84812090
- HS code
- 8481.20
Standards & Compliance
- HS Code
- 8481.20
Cross References
- EAN 4052568221102
- MPN 573821
Product Documentation
Document preview: VUWG-L10-T32C-A-M7 — Festo product documentation
More from Festo
Festo
Festo PRS-1/4-6 Manifold block
10189
Festo
Festo VL-5/3G-3/8-B-EX Pneumatic valve
536048
Festo
Festo DNC-32-250-PPV ISO cylinder
163327
Festo
Festo ADN-100-30-A-P-A Compact cylinder
536378
Festo
Festo VUVG-B18-P53C-Z-F-P1 Solenoid valve
8033568
Festo
Festo NPFC-L-2R34-M Elbow fitting
8030227
Festo
Festo LBG-32 Clevis foot
31761
Festo
Festo CPE14-M1BH-5L-QS-8 Solenoid valve
196912
Catalogue entry last verified: 2026-09-30. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy 573821?
- 573821 can be ordered from cballast.com as a Festo catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Festo product?
- The manufacturer part number is 573821.
- What is the HS code for 573821?
- The customs tariff (HS) code for 573821 is 8481.20.
- Who manufactures 573821?
- 573821 is a Festo product in the Pneumatics range.
- Is a datasheet available for 573821?
- Yes — the 573821 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for 573821?
- The minimum order quantity is 1.
- Is 573821 available?
- Yes — 573821 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
