Festo SMTO-4U-PS-K-LED-24 Proximity sensor
Pricing
Request a quote
We reply within 24 hours
Overview
Festo SMTO-4U-PS-K-LED-24 Proximity sensor (part number 152836) is listed under Pneumatics / Pneumatic Components. Type code: SMTO-4U-PS-K-LED-24; Product category: Sensors; Design: Round; Based on standard: EN 60947-5-2; Symbol: 00991152; Approval: RCM.
Technical Specifications
- Manufacturer part number (MPN)
- 152836
- Type code
- SMTO-4U-PS-K-LED-24
- EAN / GTIN
- 4052568117726
- Product category
- Sensors
- Design
- Round
- Based on standard
- EN 60947-5-2
- Symbol
- 00991152
- Approval
- RCM
- CE mark (see declaration of conformity)
- To EU EMC Directive, In accordance with EU RoHS Directive
- UKCA marking (see declaration of conformity)
- To UK RoHS instructions
- Measured variable
- Position
- Measuring principle
- Magneto-inductive
- Ambient temperature
- -25 ... 70 °C
- Repetition accuracy
- 0.2 mm
- Switching output
- PNP
- Switching element function
- N/O contact
- Switch-on time
- 5 ms
- Switch-off time
- 5 ms
- Max. output current
- 200 mA
- Max. switching capacity DC
- 6 W
- Voltage drop
- 2 V
- Inductive protective circuit
- Integrated
- Min. load current
- 0.1 mA
- Off-state current
- 0.01 mA
- Short circuit current rating
- Pulsed
- Overload protection
- Available
- Operational voltage range DC
- 10 ... 30 V
- Residual ripple
- 10%
- Reverse polarity protection
- For all electrical connections
- Electrical connection 1, connection type
- Cable
- Electrical connection 1, connector system
- Open end
- Electrical connection 1, number of connections/cores
- 3
- Connection outlet orientation
- In-line
- Cable length
- 2.5 m
- Cable characteristic
- Standard
- Cable sheath colour
- Grey
- Material cable sheath
- PVC
- Material insulating sheath
- PVC
- Wire ends
- Tin-plated
- Type of mounting
- With accessories
- Max. tightening torque
- 0.8 Nm
- Mounting position
- Any
- Product weight
- 70 g
- Housing colour
- Black
- Material housing
- PET
- Switching status indication
- Yellow LED
- Ambient temperature with moving cable
- -5 ... 70 °C
- Degree of protection
- IP67
- LABS (PWIS) conformity
- VDMA24364-B2-L
- Product type
- Pneumatic reed contacts/cables/brackets
- Product group
- Pneumatics
- Carbon footprint (EPD)
- 0.5810 kg CO2e per pcs
- Country of origin
- Switzerland
- Customs tariff code (EU CN)
- 85365019
- HS code
- 8536.50
Standards & Compliance
- HS Code
- 8536.50
Cross References
- EAN 4052568117726
- MPN 152836
Product Documentation
More from Festo
Festo
Festo VUVG-L14-P53E-ZT-G18-1P3 Solenoid valve
566511
Festo
Festo VABM-L1-10HWS1-G18-4-GR Manifold rail
8058335
Festo
Festo VUWG-L18-B52-G14 Pneumatic valve
574271
Festo
Festo AEVC Short stroke cylinder - 50mm, G1/8, 10mm, AEVC-50-10-I-P
188254
Festo
Festo LFMB-1/8-D-MINI-DA-A Fine filter
532827
Festo
Festo CRSNCS-32 Swivel flange
2895920
Festo
Festo ADVU-125-15-A-P-A Compact cylinder
175763
Festo
Festo DSBC-63-150-PPSA-N3 ISO cylinder
2126688
Catalogue entry last verified: 2026-09-29. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
