Festo LR-1/2-D-7-O-MAXI Pressure regulator

Festo LR-1/2-D-7-O-MAXI — Pressure regulator, compressed air preparation. operating pressure 0. 1.6 MPa (0. 16 bar).

Manufacturer part number (MPN)

186458

Type code

LR-1/2-D-7-O-MAXI

EAN / GTIN

4052568146634

Product category

Compressed air preparation

Lifecycle status

Phase-out

Size

Maxi

Series

D

Actuator lock

Rotary knob with detent

Mounting position

Any

Design

Piloted piston regulator

Controller function

Output pressure constant, with secondary exhausting

Symbol

00991559

Pressure gauge (ANALOG) or Pressure display (DIGITAL)

Prepared for G1/4

Operating pressure

0 ... 1.6 MPa (0 ... 16 bar)

Pressure regulation range

0.5 ... 7 bar

Max. pressure hysteresis

0.04 MPa (0.4 bar; 5.8 psi)

Standard nominal flow rate (standardised to DIN 1343)

10700 l/min

Operating medium

Compressed air to ISO 8573-1:2010 [7:4:4], Inert gas

Corrosion resistance class CRC

2 - Moderate corrosion stress

LABS (PWIS) conformity

VDMA24364-B1/B2-L

Air purity class at output

Compressed air to ISO 8573-1:2010 [7:4:4], Inert gas

Media temperature

-10 ... 60 °C

Ambient temperature

-10 ... 60 °C

Product weight

1100 g

Type of mounting

With accessories

Pneumatic connection, port 1

G1/2

Pneumatic connection, port 2

G1/2

Material sub-base

Die-cast zinc

Material seals

NBR

Material housing

Die-cast zinc

Product type

Air treatment

Product group

Pneumatics

Thread

1/2"

Press Area

0.5 to 7 bar

Carbon footprint (EPD)

6.1441 kg CO2e per pcs

Country of origin

Hungary

Customs tariff code (EU CN)

84811099

HS code

8481.10

HS Code

8481.10

• EAN 4052568146634
• MPN 186458
