Festo HE-3-3/8-QS-10 Shut-off valve

Festo HE-3-3/8-QS-10 — Shut-off valve, ball valves and on off valves. valve function 3/2-way, double solenoid; operating pressure -0.095. 1 MPa (-0.95. 10 bar); nominal size 4.6 mm.

Manufacturer part number (MPN)

153481

Type code

HE-3-3/8-QS-10

EAN / GTIN

4052568034979

Product category

Ball valves and on off valves

Valve function

3/2-way, double solenoid

Selection of additional functions

With exhaust function

Pneumatic connection, port 1

R3/8

Pneumatic connection, port 2

QS-10

Type of actuation

Manual

Type of mounting

Direct mounting via through-hole, Direct mounting via thread

Standard nominal flow rate (standardised to DIN 1343)

760.5 l/min

Nominal size

4.6 mm

Operating pressure

-0.095 ... 1 MPa (-0.95 ... 10 bar)

Ambient temperature

0 ... 60 °C

Material housing

Reinforced PBT

Operating medium

Compressed air to ISO 8573-1:2010 [7:-:-]

Exhaust-air function

Cannot be throttled

Sealing principle

Soft

Mounting position

Any

Design

Piston gate valve

Type of piloting

Direct

Flow direction

Non-reversible

Symbol

00997329

Corrosion resistance class CRC

2 - Moderate corrosion stress

LABS (PWIS) conformity

VDMA24364-B1/B2-L

Cleanroom suitability, measured according to ISO 14644-14

Class 4 according to ISO 14644-1

Media temperature

0 ... 60 °C

Product weight

60 g

Pneumatic connection, port 3

Not ducted

Material screwed plug

Nickel-plated brass

Material seals

NBR

Product type

Pneumatic flow valves

Product group

Pneumatics

Outer hose diameter

10 mm

Carbon footprint (EPD)

1.5940 kg CO2e per pcs

Country of origin

Japan

Customs tariff code (EU CN)

84812090

HS code

8481.20

HS Code

8481.20

• EAN 4052568034979
• MPN 153481
