Festo LFMB-D-MIDI-A Fine filter

Festo LFMB-D-MIDI-A — Fine filter, compressed air preparation. operating pressure 2. 12 bar.

Manufacturer part number (MPN)

192573

Type code

LFMB-D-MIDI-A

EAN / GTIN

4052568014988

Product category

Compressed air preparation

Lifecycle status

Phase-out

Series

D

Size

Midi

Design

Fibre filter

Grade of filtration

1 µm

Condensate drain

Fully automatic

Symbol

00991520

Operating pressure

2 ... 12 bar

Operating medium

Compressed air to ISO 8573-1:2010 [6:8:4], Inert gas

Air purity class at output

Compressed air to ISO 8573-1:2010 [5:7:3], Inert gas

Filter efficiency

99.99 %

Max. condensate volume

43 ml

Bowl guard

Metal bowl guard

Corrosion resistance class CRC

2 - Moderate corrosion stress

LABS (PWIS) conformity

VDMA24364-B1/B2-L

Media temperature

1.5 ... 60 °C

Ambient temperature

-10 ... 60 °C

Storage temperature

-10 ... 60 °C

Residual oil content

0.5 mg/m³

Type of mounting

With accessories

Mounting position

Vertical +/-5°

Pneumatic connection, port 1

Sub-base

Pneumatic connection, port 2

Sub-base

Material housing

Die-cast zinc

Material filter

Borosilicate fibre

Material bowl

Makrolon®

Product type

Air treatment

Product group

Pneumatics

Filter element

1 My

Carbon footprint (EPD)

9.9998 kg CO2e per pcs

Country of origin

Hungary

Customs tariff code (EU CN)

84213925

HS code

8421.39

HS Code

8421.39

• EAN 4052568014988
• MPN 192573
