Festo FRC-1/8-D-MINI-KC-A Service unit combination

Festo FRC-1/8-D-MINI-KC-A — Service unit combination, compressed air preparation. operating pressure 0.15. 1.2 MPa (1.5. 12 bar; 21.75. 174 psi).

Manufacturer part number (MPN)

185816

Type code

FRC-1/8-D-MINI-KC-A

EAN / GTIN

4052568145743

Product category

Compressed air preparation

Lifecycle status

Phase-out

Size

Mini

Series

D

Actuator lock

Rotary knob with detent

Mounting position

Vertical +/-5°

Grade of filtration

40 µm

Condensate drain

Fully automatic

Design

Proportional standard mist lubricator

Max. condensate volume

22 ml

Bowl guard

Metal bowl guard

Symbol

00991548

Pressure gauge (ANALOG) or Pressure display (DIGITAL)

With pressure gauge

Operating pressure

0.15 ... 1.2 MPa (1.5 ... 12 bar; 21.75 ... 174 psi)

Pressure regulation range

0.05 ... 1.2 MPa (0.5 ... 12 bar; 7.25 ... 174 psi)

Max. pressure hysteresis

0.02 MPa (0.2 bar; 2.9 psi)

Standard nominal flow rate (standardised to DIN 1343)

640 l/min

Operating medium

Inert gas

Corrosion resistance class CRC

2 - Moderate corrosion stress

LABS (PWIS) conformity

VDMA24364-B1/B2-L

Air purity class at output

Compressed air to ISO 8573-1:2010 [7:4:-], Inert gas

Media temperature

-10 ... 60 °C

Ambient temperature

-10 ... 60 °C

Product weight

1400 g

Type of mounting

With accessories

Pneumatic connection, port 1

G1/8

Pneumatic connection, port 2

G1/8

Material housing

Die-cast zinc

Material bowl

Makrolon®

Product type

Air treatment

Product group

Pneumatics

Thread

1/8"

Press Area

0.5 to 12 bar

Filter element

40 My

Carbon footprint (EPD)

30.7069 kg CO2e per pcs

Country of origin

Hungary

Customs tariff code (EU CN)

84811005

HS code

8481.10

HS Code

8481.10

• EAN 4052568145743
• MPN 185816
