Festo CPV14-M1H-5JS-K-1/8 Solenoid valve

Festo CPV14-M1H-5JS-K-1/8 — Solenoid valve, universal valve modules. valve function 5/2-way, double solenoid; operating pressure -0.09. 1 MPa (-0.9. 10 bar); nominal size 6 mm.

Manufacturer part number (MPN)

559651

Type code

CPV14-M1H-5JS-K-1/8

EAN / GTIN

4052568206277

Product category

Universal valve modules

Valve function

5/2-way, double solenoid

Type of actuation

Electrical

Valve size

14 mm

Standard nominal flow rate (standardised to DIN 1343)

800 l/min

pneumatic working port

G1/8

Operating voltage

24 V DC

Operating pressure

-0.09 ... 1 MPa (-0.9 ... 10 bar)

Design

Piston gate valve

Degree of protection

IP65

Nominal size

6 mm

Exhaust-air function

Cannot be throttled

Sealing principle

Soft

Mounting position

Any

Manual override

Detenting, Non-detenting

Type of piloting

Piloted

Pilot air supply

External, Internal

Flow direction

Non-reversible

Symbol

00991683

lap

Overlap

Pilot pressure

0.3 ... 0.8 MPa (3 ... 8 bar)

b value

0.42

C value

3.2 l/sbar

Switching time reversal

12 ms

Duty cycle

100% in conjunction with holding current reduction

Electrical power consumption

0.65 W

Max. positive test pulse with 0 signal

1400 µs

Max. negative test pulse with 1 signal

400 µs

Operating medium

Compressed air to ISO 8573-1:2010 [7:4:4]

Vibration resistance

Transport application test with severity level 2 to FN 942017-4 and EN 60068-2-6

Shock resistance

Shock test with severity level 2 to FN 942017-5 and EN 60068-2-27

Corrosion resistance class CRC

2 - Moderate corrosion stress

LABS (PWIS) conformity

VDMA24364-B1/B2-L

Storage temperature

-20 ... 40 °C

Media temperature

-5 ... 50 °C

Ambient temperature

-5 ... 50 °C

Product weight

120 g

Type of mounting

With through-hole

Pilot air port 12/14

Common line

Pilot exhaust port 82/84

Common line

Pneumatic connection, port 1

Common line with pressure separation

Pneumatic connection, port 2

G1/8

Pneumatic connection 3/5 combined

Common line

Pneumatic connection, port 4

G1/8

Material seals

HNBR, NBR

Material housing

Die-cast aluminium, Brass, POM, PPS, Steel

Product type

Pneumatic solenoid valves

Product group

Pneumatics

Carbon footprint (EPD)

2.4599 kg CO2e per pcs

Country of origin

Germany

Customs tariff code (EU CN)

84812090

HS code

8481.20

HS Code

8481.20
