Festo CLR-63-20-L-P-A-K11-R8 Linear/swivel clamp

Festo CLR-63-20-L-P-A-K11-R8 — Linear/swivel clamp, swing clamp cylinders. piston diameter 63 mm; operating pressure 2. 10 bar.

Manufacturer part number (MPN)

535506

Type code

CLR-63-20-L-P-A-K11-R8

EAN / GTIN

4052568169176

Product category

Swing clamp cylinders

Total stroke

43 mm

Piston diameter

63 mm

Piston rod thread

M10

Swivel angle

90 deg +/-2 deg

Clamping stroke

20 mm

Cushioning

Elastic cushioning rings/plates at both ends

Mounting position

Any

Design

Piston, Piston rod, Cylinder barrel

Position detection

Via proximity switch

Swivel direction

left

Symbol

00991217

Variants

Weld spatter protection, Dust protection

Operating pressure

2 ... 10 bar

Mode of operation

Double-acting

Operating medium

Compressed air to ISO 8573-1:2010 [7:4:4]

Corrosion resistance class CRC

2 - Moderate corrosion stress

LABS (PWIS) conformity

VDMA24364-B2-L

Ambient temperature

-10 ... 80 °C

Effective clamping force at 0.2 MPa (2 bar, 29 psi)

441 N

Effective clamping force at 0.4 MPa (4 bar, 58 psi)

823 N

Effective clamping force at 0.6 MPa (6 bar, 87 psi)

1386 N

Max. tightening torque Clamping finger screw

47 Nm

Theoretical clamping force at 0.6 MPa (6 bar, 87 psi)

1682 N

Product weight

2100 g

Type of mounting

With through-hole, with female thread, with accessories

Pneumatic connection

G1/8

Material wiper

PPS

Material collar screws

Steel, Galvanised

Material cover

Wrought aluminium alloy, coated

Material seals

NBR, TPE-U(PU)

Material housing

Smooth-anodised

Material piston rod

coated, High-alloy stainless steel

Material cylinder barrel

Wrought aluminium alloy, Smooth-anodised

Product type

Pneumatic ISO compact air cylinders

Product group

Pneumatics

Port Size

G1/8

Carbon footprint (EPD)

36.2717 kg CO2e per pcs

Country of origin

China

Customs tariff code (EU CN)

84799070

HS code

8479.90

HS Code

8479.90
