Festo ADVU-125-80-A-P-A Compact cylinder

Festo ADVU-125-80-A-P-A — Compact cylinder, pneumatic cylinders. stroke 80 mm; piston diameter 125 mm; operating pressure 0.05. 1 MPa (0.5. 10 bar; 7.25. 145 psi).

Manufacturer part number (MPN)

175770

Type code

ADVU-125-80-A-P-A

EAN / GTIN

4052568143404

Product category

Pneumatic cylinders

Stroke

80 mm

Piston diameter

125 mm

Piston rod thread

M27x2

Cushioning

Elastic cushioning rings/plates at both ends

Mounting position

Any

Mode of operation

Double-acting

Piston-rod end

Male thread

Design

Piston, Piston rod

Position detection

Via proximity switch

Symbol

00991217

Variants

Piston rod at one end

Operating pressure

0.05 ... 1 MPa (0.5 ... 10 bar; 7.25 ... 145 psi)

Operating medium

Compressed air to ISO 8573-1:2010 [7:4:4]

Corrosion resistance class CRC

2 - Moderate corrosion stress

LABS (PWIS) conformity

VDMA24364-B1/B2-L

Ambient temperature

-20 ... 80 °C

Impact energy in end positions

3.3 J

Theoretical force at 0.6 MPa (6 bar, 87 psi), return strok

6881 N

Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stro

7363 N

Moving mass for 0 mm stroke

1317 g

Additional moving mass per 10 mm stroke

63 g

Basic weight for 0 mm stroke

3426 g

Additional weight per 10 mm stroke

168 g

Type of mounting

With through-hole, with accessories

Pneumatic connection

G1/4

Material collar screws

Galvanised steel

Material cover

Painted die-cast aluminium

Material dynamic seals

NBR, TPE-U(PU)

Material piston rod

High-alloy steel

Material cylinder barrel

Wrought aluminium alloy

Product type

Pneumatic ISO compact air cylinders

Product group

Pneumatics

Port Size

G1/4

Carbon footprint (EPD)

65.6610 kg CO2e per pcs

Country of origin

Hungary

Customs tariff code (EU CN)

84123100

HS code

8412.31

HS Code

8412.31

• EAN 4052568143404
• MPN 175770
