Multimeter BM 829 TRUE RMS.

Elma Instruments 42829 Elma 829. True RMS category IV multimeter.

Manufacturer part number (MPN)

42829

EAN / GTIN

5706445410323

Sales unit

pcs

Package quantity

20 pcs

Current supply

Battery

Measured value memory

No

Indication

Digital

Measuring range selection

Automatic

True RMS measurement

Yes

Continuity test

Yes

Interface

Yes

Capacitance measurement

Yes

Frequency measurement

Yes

With decibel measurement (dB)

No

Measurement principle

True root mean square

Data hold

Yes

IR interface

Yes

Relative measurement accuracy

0.08 %

Explosion-tested version

No

Analogue bar graph display

Yes

Bluetooth interface

No

Resistance test/diode test

Yes

Inductance measurement

No

Lowest resolution, DC voltage

0.1 mV

Lowest resolution, AC voltage

0.1 mV

Lowest resolution, resistance

0.1 Ohm

With conductivity measurement

No

Max. voltage measuring range AC

1000 V

Max. voltage measuring range DC

1000 V

Max. current measuring range, AC

10 A

Max. current measuring range, DC

10 A

Max. resistance measuring range

60 MOhm

Max. value storage

Yes

Multiple display

Yes

Measuring circuit category

CAT IV

Min. value storage

Yes

Nominal test voltage 100 V

No

Nominal test voltage 1000 V

Yes

Nominal test voltage 250 V

No

Nominal test voltage 500 V

No

Relative value measurement

No

Peak value memory

No

Duty cycle measurements

No

Temperature measurement

Yes

Calibration according to ISO/IEC 17025

No

Max. temperature measuring range

1000 °C

Lowest resolution temperature

1 °C

Max. capacitance measuring range

27000 µF

Max. frequency measuring range

100 kHz

Lowest resolution, frequency

0.1 Hz

Analogue bar graph display analogue/logarithmical

Yes

Temperature measurement RTD

No

Temperature measurement TC

Yes

Nominal test voltage 10 V

No

Nominal test voltage 50 V

No

Cable length measurement

No

Cable symmetry testing for two wire connections a-b-E

No

Power and energy measurement

No

Harmonics analysis/power quality

Yes

Rotational speed measuring

No

Automatic circuit breaker

No

Max. voltage measuring circuit category

1000 V

With display backlight

Yes

Scaling bar graph linear

Yes

Scaling bar graph logarithmic

No

High voltage test for motor windings

No

Clip factors for current sensor

1:1

Clip factors for current transformer

1:1

Max. voltage measuring range AC/DC

1000 V

Lowest resolution, AC/DC voltage

60 mV

Max. current measuring range, AC/DC

10 A

Lowest resolution, AC/DC current

1 µA

HS Code

9030.89

• EAN 5706445410323
• SAP 1000055310
• Code 8845342
