Wireless Dim All (CPAD-00/213)
Pricing
Request a quote
We reply within 24 hours
Product Description
Wireless Dim All starter kit comes pre-programmed with a single xComfort push-button and a universal 250 W dimming actuator.
Technical Specifications
- Manufacturer part number (MPN)
- CPAD-00/213
- EAN / GTIN
- 9010238033528
- Sales unit
- pcs
- Package quantity
- 15 pcs
- Product segment
- Smart home
- Eaton catalogue number
- 193728
- Depth
- 223 mm
- Height
- 31 mm
- Width
- 111 mm
- Weight
- 0.216 kg
- Compliances
- RoHS conform
- Used with
- 55 mm (Universal) pushbutton
- Features
- Radio frequent bidirectional
- Bus system operating type
- Radio frequent; Other
- Actuation function
- Dimming
- Bus system product type
- Package: actuator, pushbutton
- Built-in installation box depth - min
- 18 mm
- Frequency rating - max
- 50 Hz
- Frequency rating - min
- 50 Hz
- Number of gangs (rocker)
- 1
- Output power - max
- 250 W
- Fitted with
- LED indication; Bus connection
- Switching power LED - max
- 100 W
- Voltage rating - max
- 253 V
- Voltage rating - min
- 196 V
- Width in number of modular spacings
- 3
- Power supply
- Mains; Battery
- Color
- Pure white
- Number of outputs
- 1
- Degree of protection
- IP20
- Load type
- Universal and LED retrofit
- Model
- Dimming actuator
- Mounting method
- Surface mounting; Flush mounted (plaster); Flush mounting
- Suitable for
- Constant current; Constant voltage
- Bus system KNX Secure
- No
- Bus system KNX Secure-RF (Radio Frequency)
- No
- Device emplacement
- Indoor positioning
- RAL-number
- 9010
- Frequency
- 50 Hz
- Bus system KNX
- No
- Bus system radio frequency
- Yes
- Bus system Powernet
- No
- With bus connection
- Yes
- Type of load
- Universal and LED Retrofit
- Material
- Polycarbonate (PC)
- Voltage
- 196–253 V
- Bus system LON
- No
- Substation input
- No
- Parallel-service possible
- No
- Local operation/hand operation
- No
- Output power
- 0–250 W
- With LED indication
- Yes
- Power boost suitable
- No
- Bus system KNX-RF (Radio Frequency)
- No
- Radio frequency bidirectional
- Yes
- Suitable for constant current
- Yes
- Suitable for constant voltage
- Yes
- Constant light output (CLO)
- Yes
- Bus module detachable
- No
- Min. depth of built-in installation box
- 18 mm
- Max. switching power LED
- 100 W
- Country of origin
- Czechia
