Eaton
Contactor 4S Modular (Z-SCH230/63-40)
Part numberZ-SCH230/63-40EAN / GTIN4015082488567HS code8536.90
Electrical Components
Contactors
MOQ:1
Pricing
Request a quote
We reply within 24 hours
Product Description
Eaton Z-SCH230/63-40 Contactor, Un: 230/400 V /50Hz, In: 25, 40 and 63 A AC1.
Technical Specifications
- Manufacturer part number (MPN)
- Z-SCH230/63-40
- EAN / GTIN
- 9007912220657
- HS code
- 8536.90
- Sales unit
- pcs
- Package quantity
- 40 pcs
- Eaton catalogue number
- 248856
- Depth
- 85 mm
- Height
- 60 mm
- Width
- 52.5 mm
- Weight
- 0.36 kg
- Compliances
- RoHS conform
- Features
- Additional equipment possible
- Amperage Rating
- 63 A
- Ambient operating temperature - min
- -40 °C
- Equipment heat dissipation, current-dependent
- 30.6 W
- Heat dissipation capacity
- 0 W
- Heat dissipation per pole, current-dependent
- 0 W
- Rated operational current for specified heat dissipation (In)
- 63 A
- Static heat dissipation, non-current-dependent
- 0 W
- Incandescent lamp load - max
- 7740 W
- Load fluorescent lamp - max
- 4060 VA
- Load fluorescent lamp (duo circuit) - max
- 8120 VA
- Load fluorescent lamp (parallel compensated) - max
- 2668 VA
- Rated operating voltage (Ue) - max
- 440 V
- Rated operating voltage (Ue) - min
- 440 V
- Voltage rating (excitation) - max
- 253 V
- Voltage rating (excitation) - min
- 195.5 V
- Voltage type
- AC
- Built-in depth
- 60 mm
- Degree of protection
- IP40
- Number of contacts (normally closed contacts)
- 0
- Number of contacts (normally open contacts)
- 4
- Number of modular spacings
- 3
- Utility category
- 1
- Utilization category (according to EN IEC 60947-4-1)
- AC-1
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 9007912220657
- SAP 1000073163
- Code 8791106
Product Documentation
Document preview: Contactor 4S Modular (Z-SCH230/63-40) — Specification Data Sheet (OEM)
