Undervoltagestrigger (U-PKZ0(24VDC))
Pricing
Request a quote
We reply within 24 hours
Overview
Eaton Undervoltagestrigger (U-PKZ0(24VDC)) is listed under Electrical Components / Circuit Breaker Accessories. Sales unit: pcs; Package quantity: 2 pcs; Eaton catalogue number: 157862; Depth: 68 mm; Height: 90 mm; Width: 24 mm.
Technical Specifications
- Manufacturer part number (MPN)
- U-PKZ0(24VDC)
- EAN / GTIN
- 4015081544523
- Sales unit
- pcs
- Package quantity
- 2 pcs
- Eaton catalogue number
- 157862
- Depth
- 68 mm
- Height
- 90 mm
- Width
- 24 mm
- Weight
- 0.137 kg
- Certifications
- UL; IEC/EN 60947-4-1; CSA; UL Category Control No.: NLRV; UL File No.: E36332; CE; UL 508; CSA File No.: 165628; CSA Class No.: 3211-05; CSA-C22.2 No. 14
- Ambient operating temperature - max
- 55 °C
- Ambient operating temperature - min
- -25 °C
- Number of contacts (change-over contacts)
- 0
- Number of contacts (normally closed contacts)
- 0
- Number of contacts (normally open contacts)
- 0
- Static heat dissipation, non-current-dependent Pvs
- 0.5 W
- Rated operational voltage (Ue) at AC - max
- 480 V
- Rated operational voltage (Ue) at AC - min
- 42 V
- Rated operational voltage (Ue) at DC - max
- 250 V
- Rated operational voltage (Ue) at DC - min
- 24 V
- Electric connection type
- Screw connection
- Mounting position
- Can be fitted to left side of the motor protection switch
- Product category
- Accessories
- Suitable as
- EMERGENCY STOP or EMERGENCY switching-off device in accordance with IEC/EN 60204 when combined with circuit breaker
- Suitable for
- Motor safety switch
- Used with
- Motor protective circuit-breaker
- Voltage type
- DC
- Drop-out voltage
- 0,7- 0,35 x Uc
- Pick-up voltage
- 0.85 - 1.1 V x Uc
- Rated control supply voltage (Us) at DC - max
- 24 V
- Power consumption (pick-up) at DC
- 3 W
- Power consumption (sealing) at DC
- 0.5 W
- Terminal capacity (solid/flexible with ferrule)
- 2 x (0.75 - 2.5) mm²; 1 x (0.75 - 2.5) mm²
- Terminal capacity (solid/stranded AWG)
- 1 x (18 - 14); 2 x (18 - 14)
- Delayed
- No
- Suitable for off-load switch
- No
- Suitable for overload relay
- No
- Type of electric connection
- Screw connection
- Rated control supply voltage DC
- 0–24 V
- Suitable for motor safety switch
- Yes
- Suitable for power circuit breaker
- No
- Voltage type for actuating
- DC
- Country of origin
- Germany
Standards & Compliance
- HS Code
- 8538.90
Cross References
- EAN 4015081544523
- SAP 1200236413
- Code 82234187
